SCHNEIDER BMXDDI6402K Modicon X80 Discrete Input Module
Item NO.:
BMXDDI6402KPayment:
T/TPrice:
$650Product Origin:
JapanColor:
NEWProduct weight:
0.21KGLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
The Schneider Electric BMXDDI6402K is a 64-channel discrete input module for the Modicon X80 PLC platform. It receives 24 V DC signals from industrial sensors, switches, and other field devices, allowing PLC controllers to monitor equipment status and operating conditions.
|
Parameter |
Specification |
|---|---|
|
Brand |
Schneider Electric |
|
Model |
BMXDDI6402K |
|
Product Series |
Modicon X80 |
|
Product Type |
Discrete Input Module |
|
Number of Inputs |
64 |
|
Rated Input Voltage |
24 V DC |
|
Input Type |
Isolated digital inputs |
|
Input Logic |
Positive logic (sink) |
|
Input Current |
0.6 mA typical, depending on specification revision |
|
Sensor Supply Range |
19–30 V DC |
|
Input Impedance |
40 kΩ |
|
Typical Response Time |
4 ms |
|
Maximum Response Time |
7 ms |
|
Power Dissipation |
4.3 W maximum |
|
Electrical Connection |
2 × 40-way connectors |
|
Protection Rating |
IP20 |
|
Operating Temperature |
0–60°C |
|
Weight |
Approx. 0.145 kg |
64 digital input channels for high-density signal acquisition.
Supports standard 24 V DC industrial signals.
Isolated input design for reliable signal monitoring.
LED indicators for module status and channel diagnostics.
Compatible with supported Modicon X80 PLC configurations.
Industrial machine status monitoring
Proximity sensor and limit switch monitoring
Conveyor and packaging automation
Manufacturing production lines
PLC-based process control
Verify compatibility with the Modicon M340 or M580 rack configuration.
Use the correct 40-way connectors and follow the wiring diagram.
Provide appropriate external fast-acting fuses for the input groups.
Confirm field signal polarity and voltage before connecting devices.
