SCHNEIDER BMXAMO0802 Modicon X80 Analog Output Module
Item NO.:
BMXAMO0802Payment:
T/TPrice:
$650Product Origin:
JapanColor:
NEWProduct weight:
0.21KGLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
The Schneider Electric BMXAMO0802 is an 8-channel analog current output module for the Modicon X80 PLC platform. It converts PLC control values into analog current signals for regulating valves, actuators, and other industrial process equipment. It is designed for compatible Modicon M340 and M580 automation systems.
|
Parameter |
Specification |
|---|---|
|
Brand |
Schneider Electric |
|
Model |
BMXAMO0802 |
|
Product Series |
Modicon X80 |
|
Product Type |
Analog Output Module |
|
Number of Outputs |
8 |
|
Output Signal |
0–20 mA, 4–20 mA |
|
Resolution |
16-bit |
|
Output Load Impedance |
350 Ω maximum |
|
Conversion Time |
4 ms maximum |
|
Accuracy |
±0.25% of full scale over 0–60°C |
|
Channel Isolation |
Non-isolated |
|
Power Supply |
Supplied via PLC rack |
|
Power Consumption |
3.9 W maximum at 24 V DC, plus 3.3 V supply consumption |
|
Electrical Connection |
1 × 20-way connector |
|
Protection Rating |
IP20 |
|
Operating Temperature |
0–60°C |
|
Weight |
Approx. 0.15 kg |
Eight analog current output channels.
Supports standard 0–20 mA and 4–20 mA control signals.
16-bit resolution for precise process control.
Open-circuit detection in 4–20 mA mode.
Configurable output fallback behavior.
Compact design for Modicon X80 PLC racks.
Control valve positioning
Flow and pressure regulation
Industrial process control
Chemical and manufacturing automation
PLC-based actuator control
Verify compatibility with the installed Modicon M340 or M580 PLC configuration.
Confirm the required output current range and load impedance.
Because the channels are non-isolated, check grounding and signal common requirements.
Ensure the correct 20-way connector and field wiring are used.
