SCHNEIDER A9S66391 Switch Disconnector
Item NO.:
A9S66391Payment:
T/TPrice:
$650Product Origin:
JapanColor:
NEWProduct weight:
0.21KGLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
Product Overview
The SCHNEIDER A9S66391 is an Acti9 iSW switch disconnector, rated 3P, 100 A, 415 V AC. It is designed for circuit control and electrical isolation and complies with IEC/EN 60947-3. It can also be fitted with an optional OF auxiliary contact.
| Specification | Details |
|---|---|
| Brand | Schneider Electric |
| Model | A9S66391 |
| Series | Acti9 iSW |
| Product Type | Switch Disconnector |
| Poles | 3P |
| Rated Current | 100 A |
| Rated Voltage | 415 V AC |
| Frequency | 50/60 Hz |
| Rated Insulation Voltage | 500 V AC |
| Mounting | 35 mm DIN Rail |
| Protection | IP20 / IP40 in enclosure |
| Electrical Endurance | Up to 10,000 cycles |
| Mechanical Endurance | Up to 20,000 cycles |
| Dimensions | 54 × 85 × 73 mm |
| Width | 6 × 9 mm modules |
| Standard | IEC/EN 60947-3 |
| Operating Temperature | -25°C to +60°C |
The above specifications are supported by Schneider Electric product documentation and catalog data.
