SCHNEIDER A9F55116 Miniature Circuit Breaker
Item NO.:
A9F55116Payment:
T/TPrice:
$650Product Origin:
JapanColor:
NEWProduct weight:
0.21KGLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
The SCHNEIDER A9F55116 is an Acti9 iC60H 1-pole miniature circuit breaker (MCB) with a 16 A rated current and D trip curve. It provides thermal-magnetic protection against overload and short circuits.
| Item | Specification |
|---|---|
| Brand | SCHNEIDER ELECTRIC |
| Model | A9F55116 |
| Series | Acti9 iC60H |
| Product Type | Miniature Circuit Breaker (MCB) |
| Poles | 1P |
| Rated Current | 16 A |
| Trip Curve | D |
| Trip Technology | Thermal-magnetic |
| Rated Voltage | 240 VAC |
| Frequency | 50/60 Hz |
| Breaking Capacity (Icn) | 10 kA @ 240 VAC |
| Icu | 15 kA @ 220–240 VAC |
| Magnetic Trip | 12 × In ±20% |
| Insulation Voltage (Ui) | 500 VAC |
| Impulse Withstand (Uimp) | 6 kV |
| Mounting | 35 mm DIN rail |
| Width | 18 mm |
| Height | 85 mm |
| Depth | 78.5 mm |
| Protection | IP20 |
| Standards | IEC/EN 60898-1, IEC/EN 60947-2 |
The D-curve version is intended for circuits with higher inrush currents, while maintaining overload and short-circuit protection.
