PROSOFT MVI56E-MNET Modbus TCP Communication Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

• • • • • • • •

              • PROSOFT MVI56E-MNET Modbus TCP/IP Communication Module

                The PROSOFT MVI56E-MNET is a Modbus TCP/IP Client/Server Enhanced Communication Module for the Rockwell Automation ControlLogix 1756 platform. It provides an Ethernet interface between ControlLogix processors and Modbus TCP/IP-compatible PLCs, PACs, instruments, drives, and other devices.

                Key Technical Specifications

                Parameter	Specification
                Brand	ProSoft Technology
                Model	MVI56E-MNET
                Product Type	Modbus TCP/IP Communication Module
                Platform	Rockwell Automation ControlLogix
                Module Type	Client / Server
                Backplane	1756 ControlLogix, single slot
                Ethernet	10/100 Mbps
                Ethernet Connector	RJ45
                Protocol	Modbus TCP/IP
                Client Connections	1 client connection
                Server Connections	Up to 10 independent connections
                Data Memory	Up to 5,000 × 16-bit registers
                Power Consumption	800 mA @ 5 VDC; 3 mA @ 24 VDC
                Operating Temperature	0 to 60°C
                Storage Temperature	-40 to 85°C
                Configuration	ProSoft Configuration Builder
                Diagnostics	4-character scrolling LED display

                The module supports both Modbus TCP Client (Master) and Server (Slave) functions. It can actively read/write data from Modbus TCP devices and exchange data with the ControlLogix processor.

                Features & Advantages

                • Modbus TCP/IP Client and Server functionality
                • Direct integration with ControlLogix 1756 systems
                • 10/100 Mbps Ethernet communication
                • Supports up to 5,000 16-bit registers
                • CIPconnect support for remote configuration and diagnostics
                • Built-in scrolling diagnostic display
                • Non-volatile configuration storage
                • Supports Modbus data types and configurable floating-point data movement

                Typical Applications

                • PLC-to-PLC communication
                • ControlLogix and Modicon integration
                • Industrial Ethernet networks
                • SCADA systems
                • Drives and instrumentation
                • Process automation
                • Factory automation
                • Data acquisition and monitoring
