  • PROSOFT MVI56-PDPMV1 PROFIBUS DP Master Module

    Product Description

    The PROSOFT MVI56-PDPMV1 PROFIBUS DP Master Module is an industrial communication module designed for the Rockwell Automation ControlLogix platform. It provides a communication interface between ControlLogix processors and PROFIBUS DP/DPV1 slave devices, enabling data exchange with remote I/O systems, motor drives, sensors, and other field devices.

    The module operates as a PROFIBUS DPV1 Master, transferring input and output data between PROFIBUS devices and the ControlLogix processor memory through the backplane.

    Detailed Specifications

    Parameter	Specification
    Manufacturer	ProSoft Technology
    Model	MVI56-PDPMV1
    Product Type	PROFIBUS DP Master Communication Module
    Platform	Rockwell ControlLogix
    Protocol	PROFIBUS DP / DPV1 Master
    PROFIBUS Interface	RS-485, Optically Isolated
    Connector	DB-9 Female
    Maximum Baud Rate	Up to 12 Mbps
    Maximum Slaves	Up to 125 devices (with repeater)
    Cyclic Data Capacity	Up to 1536 bytes Input / 1536 bytes Output
    Communication	DPV1 Acyclic Read/Write
    Power Consumption	800 mA @ 5 VDC, 3 mA @ 24 VDC
    Operating Temperature	0°C to 60°C
    Mounting	ControlLogix Rack



    Advantages & Features

    • Provides direct PROFIBUS DP connectivity for ControlLogix systems
    • Supports PROFIBUS DPV1 master communication
    • Compatible with remote I/O, drives, and field devices
    • Supports cyclic process data exchange and acyclic parameter communication
    • Built-in diagnostics for network and slave status monitoring
    • Supports PROFIdrive parameter communication
    • Multiple modules can be installed in one ControlLogix rack
    • Improves integration between Rockwell PLC systems and PROFIBUS networks



    Applications

    • Industrial automation systems
    • Remote I/O networks
    • Variable frequency drive communication
    • Motor control centers (MCC)
    • Factory production lines
    • Process control systems
    • Machine automation equipment

    Precautions

    • Confirm compatibility with the ControlLogix chassis and processor firmware.
    • Verify PROFIBUS slave GSD configuration before commissioning.
    • Check PROFIBUS cable shielding and termination resistors.
    • Ensure correct node address settings.
    • Disconnect power before installing or removing the module.
