NI cDAQ-9181 781496-01 CompactDAQ Ethernet Chassis

Item NO.:
781496-01
Payment:
T/T
Price:
$840
Product Origin:
USA
Color:
NEW
Goods stock:
3
Product weight:
0.23KG
Lead Time:
In stock

NI cDAQ-9181 781496-01 CompactDAQ Ethernet Chassis

Product Type: CompactDAQ Ethernet Chassis
Model: cDAQ-9181
Part Number: 781496-01
Manufacturer: National Instruments (NI)

Technical Specifications

Parameter	Specification
Chassis Type	CompactDAQ Ethernet Chassis
Module Slots	1 C Series I/O Slot
Network Interface	Ethernet
Ethernet Speed	10/100 Mbps
Ethernet Connector	RJ-45
Communication	TCP/IP, UDP
High-Performance Data Streams	Up to 6
Input FIFO	127 samples
Timing Resolution	12.5 ns
Timing Accuracy	50 ppm of sample rate
General-Purpose Counters/Timers	4 × 32-bit
Input Voltage	9–30 VDC
Maximum Power Consumption	5 W
Operating Temperature	0°C to 55°C
Protection Rating	IP30
Weight	Approx. 470 g
Dimensions	Approx. 194 × 88.7 × 33.6 mm

The cDAQ-9181 is a compact, 1-slot Ethernet chassis designed for distributed sensor measurement. It provides timing, synchronization, and data transfer between a C Series I/O module and an external computer.

Advantages & Features

Compact 1-Slot Design: Ideal for small and distributed measurement systems.
Ethernet Connectivity: Provides convenient remote communication with a host computer.
Flexible I/O: Supports a wide range of NI C Series analog, digital, and measurement modules.
Integrated Counters/Timers: Includes four 32-bit general-purpose counters/timers.
Precise Timing: Provides 12.5 ns timing resolution and 50 ppm timing accuracy.
Industrial Mounting: Suitable for desktop or industrial installation with appropriate mounting accessories.
Low Power Consumption: Requires a 9–30 VDC supply with maximum chassis consumption of approximately 5 W.

Typical Applications

Data acquisition systems
Distributed sensor monitoring
Industrial automation
Machine condition monitoring
Temperature and pressure measurement
Vibration and strain measurement
Encoder and position measurement
PWM and frequency measurement
Automated test equipment
Research and laboratory testing
