ICS Triplex T8153 Trusted Communication Interface Adapter

Product Type: Trusted Communication Interface Adapter
Model: T8153
Manufacturer: ICS Triplex / Rockwell Automation
System: Trusted TMR Safety & Control System

The T8153 is a communication interface adapter designed to connect directly to the rear of a Trusted Communication Interface module in the T8100 Trusted Controller Chassis. It provides convenient external access to Ethernet and serial communication ports for DCS, networked PCs, peer-to-peer links, and other external systems.

Technical Specifications

The T8153 itself is primarily an interface/termination adapter; its communication capabilities are provided by the associated Trusted Communications Interface module.

Advantages & Features

• Multiple Communication Interfaces: Provides Ethernet, RS232 and RS422/485 connections in one compact assembly.
• Easy External Access: Makes the communication ports of the Trusted system readily accessible.
• Industrial Connectivity: Supports connections to DCS, SCADA, engineering PCs and other external equipment.
• Flexible Serial Communication: Four RS422/485 ports support direct and multidrop connections.
• Ethernet Connectivity: Two 10/100Base-T ports support network communication with compatible Trusted CI modules.
• Space-Saving Design: Mounts directly to the rear of the Trusted controller chassis.
• Reliable Industrial Construction: Designed for use with the Trusted safety and control platform.

Typical Applications

• Safety Instrumented Systems (SIS)
• Emergency Shutdown (ESD) systems
• Oil & gas facilities
• Petrochemical plants
• Power generation
• Process control systems
• DCS/SCADA integration
• Engineering workstation communication
• Peer-to-peer industrial communication
• Critical industrial automation

Important Notes

• T8153 is an adapter, not a standalone communication processor. It should be used with a compatible Trusted Communications Interface module such as T8151B.
• Verify the exact T8151/T8151B revision before installation because Ethernet capabilities vary between module revisions.
• For newer 100Base-T Ethernet configurations, confirm compatibility with the associated CI module.
• The adapter connects directly to the rear of the Trusted controller chassis and must be correctly seated in its connector.
• Use appropriate shielded Ethernet/serial cabling in electrically noisy industrial environments.
• Observe proper grounding and ESD precautions during installation or replacement.
• Do not confuse T8153 Communication Interface Adapter with the T8151B Communication Interface Module; they perform different functions.
