HIMA X-CB 009 04 Safety Controller Module

Product Overview

Brand: HIMA
Model: X-CB 009 04
Product Type: Redundant Connector Board / Interface Board
Series: HIMax Safety System
Application: Safety Instrumented System (SIS) Field Interface

The HIMA X-CB 009 04 is a HIMax redundant connector board designed for connecting HIMax I/O modules to field devices through system cables and Field Terminal Assemblies (FTA). It provides the electrical interface between the safety I/O module and the external field wiring system.

Important: X-CB 009 04 is not a Safety CPU or controller processing module. It is a redundant field connection board used together with HIMax I/O modules such as digital output modules.

Technical Specifications

General Data

• Brand: HIMA
• Model: X-CB 009 04
• Series: HIMax
• Type: Redundant Connector Board
• Function: I/O module field interface
• Connection Type: Cable plug connection
• Configuration: Redundant wiring design
• Installation: HIMax baseplate
• Protection Rating: IP20
• Application: Safety PLC / SIS system

Main Functions

Field Signal Interface

The X-CB 009 04 provides the connection path:

HIMax I/O Module → X-CB 009 04 → System Cable → X-FTA Field Terminal Assembly → Field Devices

Main functions:

• Field signal routing
• Redundant signal distribution
• Module-to-field electrical connection
• System cable interface
• Simplified cabinet wiring

Connector Type

Redundant Cable Plug Version

The X-CB 009 04 features:

• Cable plug interface
• Redundant field connection
• Connection through HIMax system cables
• Compatibility with Field Terminal Assemblies

Compared with:

• X-CB 009 03: Single connector board with cable plug
• X-CB 009 04: Redundant connector board with cable plug

Compatible HIMax Modules

Commonly used with:

• HIMA X-DO 24 01 Digital Output Module
• HIMA X-DO 32 01 Digital Output Module
• Other compatible HIMax I/O modules

Example configuration:

X-DO 32 01 + X-CB 009 04 + X-CA System Cable + X-FTA

provides redundant connection between the safety controller and field devices.

System Architecture

Typical HIMax safety system connection:

Features & Advantages

Redundant Safety Design

Supports redundant architectures for safety-critical applications.

Reliable Signal Transmission

Provides stable communication between I/O modules and field equipment.

Reduced Cabinet Wiring

System cable connection reduces complex point-to-point wiring.

Modular HIMax Architecture

Works with:

• Safety CPU modules
• Communication modules
• Digital I/O modules
• Analog I/O modules
• Field termination assemblies

Typical Applications

• Safety Instrumented Systems (SIS)
• Emergency Shutdown Systems (ESD)
• Fire & Gas Systems
• Oil & Gas plants
• Chemical processing
• Power generation
• Turbine protection systems
• Industrial safety automation

Compatible Equipment

Commonly used with:

• HIMA HIMax Safety Controller
• HIMax X-CPU modules
• HIMax X-COM communication modules
• HIMax X-DI / X-DO / X-AI / X-AO modules
• HIMax X-FTA field terminal assemblies
• SILworX engineering software

Installation Precautions

• Confirm compatibility between X-CB 009 04 and the I/O module model.
• Ensure correct system cable type is used.
• Check redundant wiring configuration.
• Verify grounding and shielding.
• Do not install/remove modules under power.
• Perform safety validation after replacement.
