HIMA X-CB 005 04 Safety Controller Module

Product Overview

Brand: HIMA
Model: X-CB 005 04
Product Type: Connector Board / Interface Board
Series: HIMax Safety System
Application: Safety Instrumented System (SIS) Hardware Interface

The HIMA X-CB 005 04 is a HIMax redundant connector board used in HIMA safety PLC systems. It provides the electrical and mechanical interface between HIMax I/O modules and external field wiring through system cables. It is designed for safety-critical automation applications requiring high availability and reliable signal connection.

Note: X-CB 005 04 is not a Safety CPU or controller processing module. It is a connector/interface board used together with HIMax CPU, communication, and I/O modules.

Technical Specifications

General Data

• Brand: HIMA
• Model: X-CB 005 04
• Series: HIMax
• Type: Redundant Connector Board
• Function: I/O module field connection interface
• System: HIMax Safety Controller Platform
• Mounting: HIMax baseplate
• Protection Rating: IP20
• Operating Voltage: 24 V DC system supply
• Origin: Germany

Main Functions

HIMax Module Interface

The X-CB 005 04 provides the connection between:

HIMax I/O Module → X-CB 005 04 → System Cable → Field Terminal / Field Devices

Main functions:

• Module electrical connection
• Safety signal routing
• Field wiring interface
• Redundant signal connection
• Simplified cabinet wiring

Connector Type

Redundant Cable Plug Version

The X-CB 005 04 is the redundant version with cable plug connection, allowing connection to field termination assemblies (FTA) through system cables.

Typical configuration:

• HIMax I/O module
• X-CB 005 04 redundant connector board
• X-CA system cable
• X-FTA field termination assembly

Compatible HIMax Modules

Commonly used with:

• X-DI series Digital Input Modules
• X-DO series Digital Output Modules
• X-AI series Analog Input Modules
• X-AO series Analog Output Modules
• X-MIO Mixed I/O Modules

Example:

• X-DI 32 02 + X-CB 005 04 redundant connector board configuration.

Mechanical Specifications

Features & Advantages

Redundant Safety Architecture

Supports redundant HIMax safety system configurations for high availability.

Reliable Signal Transmission

Provides stable communication between I/O modules and field devices.

Modular HIMax Design

Allows flexible combinations of:

• Safety CPU modules
• Communication modules
• I/O modules
• Field termination assemblies

Simplified Maintenance

Reduces point-to-point wiring and improves troubleshooting efficiency.

Typical Applications

• Safety Instrumented Systems (SIS)
• Emergency Shutdown Systems (ESD)
• Fire & Gas Systems (F&G)
• Turbine Protection Systems
• Oil & Gas Processing
• Chemical Plants
• Power Generation
• Industrial Safety Automation

Compatible Equipment

Commonly used with:

• HIMA HIMax Safety Controller
• HIMax X-CPU Processor Modules
• HIMax X-COM Communication Modules
• HIMax X-I/O Modules
• HIMax X-FTA Field Terminal Assemblies
• SILworX Engineering Software

Installation Precautions

• Confirm compatibility with the specific HIMax I/O module.
• Check redundant wiring configuration before installation.
• Ensure correct system cable connection.
• Maintain proper grounding and shielding.
• Do not install or remove modules while energized.
• Perform safety validation after replacement.
