HIMA X-CB 008 04 Safety Controller Module

Product Overview

Brand: HIMA
Model: X-CB 008 04
Product Type: Connector Board / Interface Board
Series: HIMax Safety System
Application: Safety Instrumented System (SIS) Hardware Interface

The HIMA X-CB 008 04 is a HIMax redundant connector board used in HIMA safety PLC systems. It provides the electrical and mechanical connection between HIMax I/O modules and field devices through a system cable / field termination assembly (FTA) interface.

Important: X-CB 008 04 is not a Safety CPU or Safety Controller Module. It is a connector board (backplane/interface component) that works together with HIMax I/O modules to build a complete safety control system.

Technical Specifications

General Data

• Brand: HIMA
• Model: X-CB 008 04
• Series: HIMax
• Type: Redundant Connector Board
• Function: Field signal interface and module connection
• System: HIMax Safety PLC Platform
• Mounting: HIMax baseplate
• Protection Rating: IP20
• Country of Origin: Germany

Main Functions

Redundant Signal Connection

The X-CB 008 04 provides a redundant connection structure between:

• HIMax I/O modules
• Field termination assemblies (FTA)
• External sensors and actuators

It allows safety-related signals to be distributed or combined for redundant operation.

System Cable Interface

Features:

• System cable connection
• Redundant field wiring support
• High-reliability signal transmission
• Module-to-field communication interface

The type 04 connector board is designed for wiring applications using field termination assembly + system cable.

Compatible HIMax Modules

Commonly used with HIMax safety modules such as:

• X-AI series Analog Input Modules
• X-DI series Digital Input Modules
• X-DO series Digital Output Modules
• X-MIO series Mixed I/O Modules

Example:

• X-AI 32 02 Analog Input Module uses X-CB 008 04 as a compatible redundant connector board option.

System Compatibility

Compatible with:

• HIMA HIMax Safety Controller Platform
• HIMax Base Plates
• HIMax I/O modules
• Safety Instrumented Systems (SIS)

Typical system components:

• X-CPU Safety Processor
• X-COM Communication Module
• X-IO Modules
• X-CB Connector Boards
• X-FTA Field Termination Assemblies

Mechanical Specifications

Features & Advantages

High Safety Availability

Supports redundant safety architectures for critical applications.

Modular HIMax Design

Allows flexible combination of:

• CPU modules
• Communication modules
• I/O modules
• Field interfaces

Reliable Field Connection

Provides stable signal transmission between field devices and safety modules.

SIL Safety System Support

Designed for HIMA HIMax safety applications requiring high reliability.

Typical Applications

• Safety Instrumented Systems (SIS)
• Emergency Shutdown Systems (ESD)
• Fire & Gas Protection Systems
• Turbine Protection Systems
• Oil & Gas Processing
• Chemical Plants
• Power Generation
• Industrial Safety Automation

Installation Precautions

• Confirm compatibility between connector board and I/O module.
• Install only in the correct HIMax baseplate slot.
• Ensure system cable and FTA connection are correct.
• Check redundant wiring configuration before commissioning.
• Follow HIMA SILworX configuration requirements.
• Do not replace components while system power is active.
