HIMA F6217 Safety Relay Module

Product Description

HIMA F6217 is not a Safety Relay Module. It is an 8-Channel Safety-Related Analog Input Module used in HIMA safety PLC systems. It is designed to acquire analog signals from field devices and transmit safety-related measurement data to the HIMA controller for processing.

The module supports 0/4…20 mA current inputs and 0…5/10 V voltage inputs, with electrical isolation and SIL 3 safety capability, making it suitable for safety instrumented systems (SIS) and critical process automation applications.

Specifications

• Brand: HIMA
• Model: F6217 / F 6217
• Product Type: Safety Analog Input Module
• Series: HIMA Safety PLC / H41q / H51q / HIMatrix compatible systems (system dependent)
• Channel Number: 8 Analog Input Channels
• Input Signal Types:
  • 0…20 mA
  • 4…20 mA
  • 0…5 V
  • 0…10 V
• Resolution: 12 bit
• Safety Level: SIL 3 (IEC 61508)
• Electrical Isolation: Safety isolation between field signals and system electronics
• Input Voltage Range: 0…5.5 V
• Maximum Input Voltage: 7.5 V
• Input Current Range: 0…22 mA (via shunt)
• Maximum Input Current: 30 mA
• Input Resistance: 100 kΩ
• Update Time: Approx. 50 ms
• Safety Time: <450 ms
• Mounting: HIMA rack / safety controller system installation

Advantages & Features

• Safety-related analog signal acquisition
• Supports SIL 3 safety applications
• 8 independent analog input channels
• Compatible with industrial transmitters and sensors
• High measurement accuracy and reliability
• Electrical isolation improves system safety
• Suitable for continuous process monitoring
• Designed for critical industrial automation systems

Applications

• Safety Instrumented Systems (SIS)
• Emergency Shutdown Systems (ESD)
• Oil & gas process control
• Chemical plants
• Power generation systems
• Industrial safety monitoring
• Pressure, temperature, flow and level monitoring

Notes

• F6217 is an analog input module, not a relay module
• Requires a compatible HIMA safety controller rack
• Verify input signal type (4–20 mA / voltage) before installation
• Check configuration parameters after replacement
• Safety-related modules should be commissioned according to HIMA procedures
