HIMA F6215 Safety Input Module

Product Description

HIMA F6215 is a Safety-Related Analog Input Module used in HIMA safety PLC systems. It is designed for acquiring analog signals from field instruments and transmitting measurement data to the safety controller for processing in safety-critical applications.

The F6215 provides 8 analog input channels and supports multiple signal types including 0…1V / 0…5V / 0…10V voltage inputs, Pt100 temperature sensors, and 0/4…20mA current inputs. It features safety isolation and galvanic isolation between channels for reliable industrial operation.

Specifications

• Brand: HIMA
• Model: F6215 / F 6215
• Product Type: Safety Analog Input Module
• Series: HIMA Safety PLC / H41q System
• Function: Analog signal acquisition
• Number of Channels: 8 Analog Inputs
• Input Signal Types:
  • 0…1 V
  • 0…5 V
  • 0…10 V
  • Pt100 RTD
  • 0/4…20 mA
• Resolution: 12 bit
• Isolation:
  • Safety isolation to plant
  • Galvanic isolation between inputs
• Input Resistance: ≥1 MΩ (voltage input)
• Current Input Shunt: 50 Ω
• Conversion Time: Max. 4 ms for 8 channels
• Basic Accuracy: Approx. 0.1% at 25°C
• Operating Error: Approx. 0.3% at 0…60°C
• Power Supply:
  • 5 V DC: approx. 100 mA
  • 24 V DC: approx. 140 mA
• Mounting: HIMA rack installation

Advantages & Features

• Safety-related analog signal monitoring
• Supports various industrial sensors and transmitters
• 8-channel design improves system integration
• High measurement accuracy with 12-bit resolution
• Electrical isolation enhances system safety
• Suitable for SIL-rated safety applications
• Modular design allows easy replacement and maintenance

Applications

• Safety Instrumented Systems (SIS)
• Emergency Shutdown Systems (ESD)
• Oil & gas process plants
• Chemical industry automation
• Power generation systems
• Pressure, temperature, flow and level monitoring
• Industrial safety control systems

Notes

• F6215 is an analog input module, not a digital safety input module or relay module
• Requires compatible HIMA safety controller hardware
• Verify signal type (4–20mA / voltage / Pt100) before replacement
• Confirm system configuration and firmware compatibility
• Safety modules should be installed and commissioned according to HIMA procedures
