                                      • Foxboro FBM237 Fieldbus Module

                                        Product Overview

                                        The Foxboro FBM237 Fieldbus Module is a 0–20 mA Analog Output Module designed for the Foxboro I/A Series / EcoStruxure Foxboro DCS Distributed Control System. It provides 8 isolated analog output channels for sending control signals from the DCS to field devices such as control valves, actuators, and other process equipment.

                                        The FBM237 supports single module operation or redundant pair configuration, improving system availability for critical industrial process control applications.

                                        ---

                                        Main Specifications

                                        • Manufacturer: Foxboro (Schneider Electric / Invensys)
                                        • Model: FBM237
                                        • Series: I/A Series 200 Fieldbus Module
                                        • Product Type:
                                          • Analog Output Module
                                          • Fieldbus Interface Module
                                          • DCS I/O Module
                                        • Function:
                                          • 0–20 mA analog output control
                                        • Output Channels:
                                          • 8 channels
                                        • Communication:
                                          • Redundant 2 Mbps Fieldbus communication



                                        ---

                                        Technical Specifications

                                        Analog Output

                                        • Number of Channels:
                                          • 8 independent analog output channels
                                        • Output Range:
                                          • 0 to 20.4 mA DC
                                        • Output Accuracy:
                                          • ±0.05% of span (0.1–20 mA range)
                                        • Resolution:
                                          • 13-bit
                                        • Maximum Load Resistance:
                                          • 750 Ω
                                        • Output Processing Delay:
                                          • ≤30 ms



                                        ---

                                        Isolation & Redundancy

                                        Channel Isolation

                                        • Each output channel is electrically isolated from:
                                          • Other channels
                                          • System ground

                                        Redundant Operation

                                        Supports:

                                        • Single module operation
                                        • Redundant pair operation

                                        Redundant configuration allows continued operation during certain module faults or replacement procedures, improving control system availability.

                                        ---

                                        Power & Communication

                                        Power Supply

                                        • Input Voltage:
                                          • 24 VDC nominal
                                        • Power Consumption:
                                          • Approx. 7 W maximum

                                        Communication Interface

                                        • Connects to:
                                          • Foxboro Fieldbus Communication Module (FCM)
                                          • Foxboro Control Processor (FCP)
                                        • Communication:
                                          • Redundant fieldbus network



                                        ---

                                        Mechanical Specifications

                                        Item	Specification
                                        Module Type	Foxboro FBM237
                                        Mounting	Modular Baseplate / DIN Rail
                                        Dimensions	Approx. 102 × 45 × 104 mm
                                        Weight	Approx. 185 g
                                        Operating Temperature	-20 to +70°C
                                        Humidity	5–95% RH (non-condensing)



                                        ---

                                        Features & Advantages

                                        • Original Foxboro I/A Series DCS module
                                        • 8-channel analog output capability
                                        • High-precision current signal control
                                        • Galvanically isolated outputs
                                        • Supports redundant system architecture
                                        • Compatible with HART-enabled field devices
                                        • Designed for continuous industrial operation
                                        • Suitable for harsh industrial environments



                                        ---

                                        Applications

                                        Used in:

                                        • Oil & gas plants
                                        • Petrochemical facilities
                                        • Power generation
                                        • Chemical processing
                                        • Water treatment systems
                                        • Industrial manufacturing

                                        Typical applications:

                                        • Control valve positioning
                                        • Actuator signal output
                                        • Process control loops
                                        • Pump and motor control
                                        • DCS output signal management

The structure and details of the product：
