Eaton PDG23G0060TFFJ Circuit Breaker

Eaton PDG23G0060TFFJ Circuit Breaker (Power Defense MCCB – 60A, Frame 2, 3-Pole)



The Eaton PDG23G0060TFFJ is a Power Defense series molded case circuit breaker (MCCB) used for industrial low-voltage power protection and distribution systems.

Product Information

• Brand: Eaton (USA)
• Series: Power Defense (PD2 Global)
• Model: PDG23G0060TFFJ
• Type: Molded Case Circuit Breaker (MCCB)
• Frame size: Frame 2
• Poles: 3-pole
• Rated current: 60A
• Voltage rating: up to 600 VAC
• Standard: UL 489 / IEC 60947-2 certified
• Interrupt rating: up to ~35 kAIC @ 480 VAC

What it actually is

This is a industrial protection breaker, meaning it:

• Protects circuits from overload
• Trips on short-circuit faults
• Used in industrial switchboards and control panels
• Handles 3-phase power distribution

It does NOT control signals or automation logic.

System Role (Simple)

Power supply (3-phase AC)
→ Eaton PDG23G0060TFFJ breaker (this unit)
→ distribution busbar
→ loads (PLC panels, drives, motors, machines)

So it acts like a “protective switch for industrial electrical systems.”

Key Features

• Thermal + magnetic trip protection system
• High short-circuit interruption capability
• Compact Frame 2 MCCB design
• Suitable for industrial switchgear
• Stable operation for continuous duty systems
• UL/IEC certified safety standard

Typical Applications

• Industrial distribution panels
• Motor control centers (MCC)
• Machinery power protection
• Factory automation systems
• UPS / electrical feeder protection
• General low-voltage switchgear systems

Advantages

• High fault current protection capability
• Reliable industrial-grade construction
• Standard global certification
• Compact installation size
• Suitable for harsh electrical environments

Important Notes

• Not PLC module ❌
• Not controller ❌
• Not sensor ❌
• Not communication device ❌
• It is a 60A molded case circuit breaker (MCCB) ✔

Precautions

• Must match correct frame (Frame 2 system)
• Must follow torque specs for terminals
• High voltage installation requires qualified electrician
• Not interchangeable with other MCCB frames
• Must be installed in approved electrical panel
