BENTLY NEVADA 330105-02-12-05-02-05 3300 XL 8 mm Reverse Mount Proximity Probe

Product Overview

The Bently Nevada 330105-02-12-05-02-05 is a 3300 XL 8 mm reverse-mount proximity probe designed for non-contact measurement of shaft displacement and vibration in rotating machinery. Using eddy-current sensing technology, it detects changes in the gap between the probe tip and a conductive target. It is designed for use with compatible extension cables and Proximitor sensors in machinery monitoring systems.

Key Technical Specifications

• Brand: Bently Nevada

• Model: 330105-02-12-05-02-05

• Product Series: 3300 XL

• Product Type: 8 mm Reverse Mount Proximity Probe

• Sensing Technology: Eddy-current, non-contact

• Probe Tip Diameter: 8 mm (0.315 in)

• Mounting Type: Reverse mount

• Probe Case Thread: 3/8-24 UNF

• Unthreaded Length Option: 0.2 in (5.1 mm)

• Probe Case Length Option: 1.2 in (30.5 mm)

• Integral Cable Length: 0.5 m (1.6 ft)

• Connector Type: Miniature ClickLoc coaxial connector

• Probe Tip Material: Polyphenylene sulfide (PPS)

• Probe Case Material: AISI 303/304 stainless steel

• Measurement Linear Range: 2 mm (80 mils) in a compatible transducer system

• System Scale Factor: 7.87 V/mm (200 mV/mil) for a compatible standard 3300 XL 8 mm system

• Frequency Response: Up to 10 kHz, depending on the complete system configuration

• Temperature Range: Approximately -52°C to +177°C (-62°F to +350°F), subject to cable and installation conditions

• Approvals: Multiple approvals, including CSA, ATEX, and IECEx

Key Features

• Non-contact measurement of shaft vibration and displacement.

• Reverse-mount configuration for installations with restricted mounting access.

• 8 mm sensing tip for compatible industrial machinery monitoring systems.

• Miniature ClickLoc coaxial connector for secure connection.

• Stainless-steel probe case for industrial environments.

• Compatible with designated 3300 XL 8 mm extension cables and Proximitor sensors.

Applications

• Steam and gas turbine monitoring

• Industrial compressor protection

• Pump and motor shaft monitoring

• Bearing vibration measurement

• Shaft displacement and position monitoring

• Machinery condition monitoring and predictive maintenance

Important Notes

• This item is a proximity probe, not a complete measurement system.

• A compatible extension cable and Proximitor sensor are required for operation.

• The listed 0.5 m length refers to the probe's integral cable; confirm the total calibrated system length before selecting additional components.

• The 7.87 V/mm scale factor applies to the compatible complete transducer system, not to the probe as a standalone device.

• Verify connector type, mounting dimensions, cable length, hazardous-area approvals, and the full part number before ordering.
