BENTLY 149992-03 Proximity Sensor System Module

Product Overview

Brand: Bently Nevada
Model: 149992-03
Series: 3500 Monitoring System
Product Type: 16-Channel Low Current Relay Output Module
Function: A relay output module used in the Bently Nevada 3500 machinery protection and condition monitoring system. It provides 16 programmable relay outputs for alarm, shutdown, and status signaling applications.

Technical Specifications

• Module Type: Low Current Relay Output Module
• System Compatibility: Bently Nevada 3500 Series Monitoring System
• Model Number: 3500/33-03-00
• Ordering Number: 149992-03
• Output Channels: 16 relay outputs
• Relay Type: Low current relay output
• Output Configuration: Independently programmable
• Logic Function:
  • AND logic
  • OR logic
  • Alarm voting logic
• Configuration Software: 3500 Rack Configuration Software
• Installation Position: Any slot to the right of TDI module in 3500 rack
• Module Height: Full-height module
• Operating Environment: Industrial machinery monitoring applications
• Weight: Approx. 0.8–1 kg
• Origin: USA

Advantages & Features

Multi-Channel Relay Output

Provides 16 independent relay outputs, allowing multiple alarms, shutdown signals, and control outputs from one module.

Flexible Alarm Logic

Each relay can be configured independently with different alarm conditions, improving system flexibility.

Reliable Machinery Protection

Designed for Bently Nevada 3500 systems used in critical rotating equipment monitoring.

Easy System Integration

Works seamlessly with Bently Nevada vibration monitoring modules and rack-based protection systems.

High Reliability Design

Suitable for continuous operation in demanding industrial environments.

Reduced Maintenance Time

Centralized relay output management simplifies troubleshooting and system maintenance.

Typical Applications

• Turbine monitoring systems
• Compressor protection systems
• Generator monitoring systems
• Pump vibration protection
• Rotating machinery condition monitoring
• Oil & gas facilities
• Power plants
• Petrochemical equipment protection

Precautions

• Confirm compatibility with the Bently Nevada 3500 rack system before installation.
• Verify relay output specifications match the connected equipment requirements.
• Configure alarm logic correctly before operation.
• Disconnect power before installing or removing the module.
• Avoid incorrect wiring of relay terminals.
• Perform functional testing after replacement.
• Keep the module in a clean, dry environment to prevent contamination.
