Bently Nevada 146031-01 3500 Rack Interface Module

Product Overview

The Bently Nevada 146031-01 is a 3500/22M Transient Data Interface (TDI) I/O Module used in the Bently Nevada 3500 Machinery Protection System. It combines the functions of a 3500/20 Rack Interface Module (RIM) and a communication processor, providing communication between the 3500 monitoring rack and System 1 Machinery Management Software.

The module captures and transfers machinery condition data, including steady-state values and transient waveform data from 3500 monitoring modules, enabling advanced vibration analysis and predictive maintenance.

Main Specifications

• Manufacturer: Bently Nevada (Baker Hughes)
• Model: 146031-01
• Series: 3500 Machinery Protection System
• Product Type:
  • Transient Data Interface (TDI) Module
  • Rack Interface Module
  • Communication Interface Module
• System Compatibility:
  • Bently Nevada 3500/22M System
• Rack Position:
  • RIM slot (Slot 1 position)
• Interface Type:
  • Ethernet 10Base-T / 100Base-TX

Communication Specifications

Ethernet Communication

• Network Interface:
  • Ethernet TCP/IP
• Transmission Type:
  • 10Base-T
  • 100Base-TX
• Communication Functions:
  • 3500 rack data transmission
  • System 1 software connection
  • Configuration communication
  • Data acquisition communication

Data Processing Functions

The 146031-01 provides access to:

• Vibration monitoring data
• Shaft displacement information
• Speed measurement data
• Alarm and event information
• Monitor module status
• Static machine condition data
• Dynamic waveform data (with optional channel enabling disk)

Technical Parameters

• Module Type: 3500/22M Transient Data Interface I/O Module
• Power Supply: Supplied through 3500 rack backplane
• Operating Temperature: Approx. -30°C to +65°C
• Storage Temperature: Approx. -40°C to +85°C
• Installation: One full-height rack slot

Features & Advantages

• Original Bently Nevada 3500 series module
• Provides communication between machinery protection system and monitoring software
• Combines rack interface and communication processor functions
• Supports real-time machinery condition data transmission
• Enables high-resolution transient waveform capture
• Improves predictive maintenance capability
• Reduces equipment downtime through early fault detection

Applications

Used in:

• Steam turbines
• Gas turbines
• Compressors
• Pumps
• Generators
• Rotating machinery monitoring systems
• Petrochemical and power plants

Typical applications:

• Vibration condition monitoring
• Machinery protection
• Predictive maintenance
• Equipment health diagnostics
