BENDER IRDH275B-435 Insulation Monitoring Device

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

BENDER IRDH275B-435 Insulation Monitoring Device

Product Overview

The IRDH275B-435 is a high-performance insulation monitoring device (IMD) designed by BENDER for ungrounded AC/DC systems (IT systems). It continuously monitors insulation resistance and triggers alarms when faults are detected, ensuring electrical safety in industrial and commercial applications .

Key Features

✅ Advanced Insulation Monitoring

• Monitors AC (0–793V) and DC (0–650V) systems, with optional voltage couplers extending to 7200V AC/1760V DC .

• Measurement Range: 1kΩ–10MΩ, with adjustable response thresholds for early warnings .

• Accuracy: ±1kΩ (1kΩ–10kΩ) / ±10% (10kΩ–10MΩ) .

✅ Smart Alarms & Diagnostics

• Dual Alarm Relays: Two SPDT contacts for fault signaling (configurable as NO/NC) .

• Self-Test & History: Automatic self-checks and event logging (up to 300 events in "B" versions) .

• Real-Time Display: Two-line LCD showing insulation resistance and system status  .

✅ Robust Industrial Desi

• Operating Temp: -40°C to +70°C, with IP30/IP20 protection for harsh environments .

• Isolation: 2500V between circuits for noise immunity .

✅ Communication & Integration

• RS485/Modbus support for SCADA or BMS integration .

• Analog Output: 0–400µA or 4–20mA for external instrumentation .

✅ Flexible Installation

• DIN Rail or Panel Mounting for easy deployment in switchgear .

• Hot-Swappable for maintenance without downtime .

Technical Specifications

Applications
