Bachmann OT115/R Panel Module

1. Product Description

An industrial-grade human-machine interface (HMI) panel module designed for on-site operation, monitoring, and configuration of Bachmann automation systems. As a dedicated panel solution, the Bachmann OT115/R integrates a compact display, tactile operation buttons, and communication interfaces to interact with controllers (e.g., MPC240), bus modules (e.g., FS212/N), and I/O modules (e.g., DIO216). It supports real-time data visualization, parameter adjustment, and fault alerts, with a rugged panel design that fits standard control cabinets—ideal for harsh industrial environments requiring intuitive local system management (e.g., production lines, process control stations).

2. Detailed Specifications

2.1 Display & Operation

Display Type: 3.5-inch TFT LCD (resolution: 320×240 pixels; backlit, 300 cd/m² brightness)

Operation Buttons: 8 tactile pushbuttons (configurable for start/stop, parameter selection, alarm reset)

Indicator Lights: 4 LED indicators (red: fault; yellow: warning; green: normal; blue: communication active)

Touch Function: Optional resistive touchscreen (for enhanced operation; compatible with gloved use)

2.2 Communication Interfaces

Primary Interface: 1×Ethernet port (10/100 Mbps, RJ45; supports Profinet, Modbus TCP)

Secondary Interface: 1×RS485 port (supports Modbus RTU; for connection to local I/O modules)

Bus Compatibility: Works with Bachmann FS212/N FAST BUS module (via Ethernet protocol conversion)

2.3 Functional Capabilities

Data Visualization: Displays real-time I/O status, process parameters (temperature, pressure), and system alarms

Configuration: Supports on-panel adjustment of controller parameters (setpoints, thresholds) and module settings

Fault Diagnostics: Logs up to 100 historical faults (timestamped; exportable via USB)

Offline Mode: Stores up to 500 MB of historical data (for post-analysis when offline)

2.4 Power Supply

Input Voltage: 24 V DC ±20% (powered via cabinet power or external adapter)

Power Consumption: Typical 6 W, Maximum 8 W (including display backlight)

Power Protection: Overvoltage, undervoltage, and reverse polarity protection

2.5 Operating Environment

Operating Temperature: -20°C ~ +60°C (optimized for panel-mounted cabinet use)

Storage Temperature: -40°C ~ +85°C

Relative Humidity: 5% ~ 95% (non-condensing)

IP Rating: IP65 (front panel; dust-tight, water-resistant for cabinet front installation)

Vibration Resistance: 10-500 Hz, 1 g acceleration (IEC 60068-2-6)

EMC Compliance: EN 61000-6-2 (industrial immunity), EN 61000-6-4 (industrial emissions)

2.6 Physical & Installation

Panel Cutout Dimensions: 100×80 mm (standard for cabinet panel mounting)

Overall Dimensions: 110×90×35 mm (Length×Width×Depth; depth includes rear connectors)

Mounting Type: Flush panel mounting (via screws; compatible with 1-3 mm thick cabinet panels)

Weight: ~250 g

Software Support: Bachmann Studio (v4.0+; panel layout customization, parameter mapping)

3. Advantages & Features

Intuitive Local Operation: 3.5-inch display + tactile buttons enable easy on-site monitoring/control (no need for external HMI devices)

Panel-Mount Optimized: IP65 front panel + standard cutout size fits seamlessly into industrial control cabinets

Multi-Protocol Compatibility: Connects to Bachmann controllers, FAST BUS modules, and I/O modules via Ethernet/RS485

Rugged Design: Wide temperature range (-20°C~+60°C) and IP65 protection suit harsh cabinet environments

Fault Logging & Data Storage: Historical fault logs and offline data storage simplify troubleshooting and analysis

4. Application Fields

Industrial Control Cabinets: Production line control cabinets (monitoring/operating conveyor systems, robotic arms)

Process Control Stations: Chemical/petroleum plant local control stations (adjusting reactor parameters, viewing pressure/temperature)

Building Automation Panels: HVAC control panels (setting temperature thresholds, monitoring airflow)

Water Treatment Units: Pump station control panels (starting/stopping pumps, checking water level alarms)

Renewable Energy Inverters: Solar/wind inverter panels (monitoring power output, adjusting grid-tie parameters)

5. Precautions

Panel Installation: Ensure cabinet panel thickness is 1-3 mm; seal around the cutout (use foam gasket) to maintain IP65 rating; avoid direct sunlight on the display (reduces backlight lifespan).

Wiring: Route communication/power cables through cabinet cable glands; separate high-voltage cables from Ethernet/RS485 wires (reduces EMI); secure connectors tightly.

Display Maintenance: Clean the front panel with a soft, dry cloth (avoid alcohol or abrasive cleaners); replace backlight if brightness decreases below 150 cd/m².

Configuration: Back up panel layout and parameter settings via Bachmann Studio (prevents data loss after module replacement); test new configurations offline before applying to live systems.

Environmental Protection: Do not expose the rear of the module (non-IP65) to water or dust; ensure cabinet ventilation (prevents overheating in high-temperature environments).
