B&R X20DO9322 Digital Output Module

B&R X20DO9322

Digital Output Module

Specifications

• Channels: 8 digital outputs
• Output type: Sourcing (PNP), 24 V DC
• Rated current: 0.5 A per channel
• Short-circuit and overload protection per channel
• Galvanic isolation: 500 V between field side and system bus
• Status LEDs for each channel and module operation
• Operating temperature: −25°C to +60°C (horizontal mounting)
• Mounting: 35 mm DIN rail, hot-swappable
• Protection class: IP20
• Power consumption: Bus 0.01 W, I/O 1.8 W

Key Features

• Compact 8-channel design saves cabinet space
• Individual channel protection enhances system reliability
• Hot-swap function allows replacement without system stop
• High EMC resistance for harsh industrial environments
• Easy configuration and diagnostics via Automation Studio

Applications

• Machine automation, packaging and material handling systems
• Control of valves, relays, contactors and indicator lights
• General discrete output control for production lines
•
