B&R X20DI9371 Digital Input Module

B&R X20DI9371

Digital Input Module

Specifications

• Channels: 8 digital inputs
• Input type: Sinking (NPN), 24 V DC compliant with EN 61131-2 Type 1
• Input current: Approx. 3 mA per channel
• Galvanic isolation: 500 V between field side and system bus
• Configurable input filter for noise suppression
• Individual LED status indicators for each channel
• Operating temperature: −25°C to +60°C (horizontal mounting)
• Mounting: 35 mm DIN rail, hot-swappable
• Protection class: IP20
• Power consumption: Bus 0.01 W, I/O 0.8 W

Key Features

• 8-channel compact design for space-saving installation
• Configurable filter adapts to noisy industrial environments
• Full galvanic isolation improves system stability
• Hot-swappable for maintenance without system shutdown
• Simple diagnosis and parameter setting via Automation Studio

Applications

• Detection of sensors, limit switches and push buttons
• Signal collection for production lines and packaging machinery
• General discrete signal acquisition in industrial automation
