B&R X20D08332 Digital Module

B&R X20DO8332

Digital Output Module

Specifications

• Channels: 8 digital outputsB& R Industrial Automation
• Output type: Sourcing (PNP), 24 VDCB& R Industrial Automation
• Rated current: 2 A per channelB& R Industrial Automation
• Connection: 1‑wire connection (common ground)B& R Industrial Automation
• Power supply: 24 VDC fed directly to the module (no bus I/O power needed)B& R Industrial Automation
• Protection: Integrated short‑circuit and overload protection per channelB& R Industrial Automation
• Isolation: Channel‑to‑bus galvanic isolationB& R Industrial Automation
• Status LEDs: Per‑channel status and module run/error indicators
• Operating temperature:
  • Horizontal: −25°C to +60°CB& R Industrial Automation
  • Vertical: −25°C to +50°CB& R Industrial Automation
• Protection class: IP20B& R Industrial Automation
• Mounting: 35 mm DIN rail, hot‑swappableB& R Industrial Automation
• Power consumption:
  • Bus: 0.22 W
  • External I/O: 0.92 W
• Certifications: CE, ATEX Zone 2, cULus, HazLoc Class I Div 2

Key Features

• High‑current outputs: 2 A per channel for driving larger loadsB& R Industrial Automation
• 1‑wire connection: Simplifies wiring, reduces cabinet spaceB& R Industrial Automation
• Integrated power feed: No separate I/O supply module requiredB& R Industrial Automation
• Parallelable outputs: Channels can be paralleled for higher currentB& R Industrial Automation
• Robust protection: Per‑channel overload and short‑circuit protectionB& R Industrial Automation
• Hot‑swap: Replace module without stopping the systemB& R Industrial Automation

Applications

• Control of high‑current actuators: Relays, contactors, solenoid valves, motorsB& R Industrial Automation
• Packaging machines, material handling, process automationB& R Industrial Automation
• General‑purpose discrete output control with higher power requirementsB& R Industrial Automation
