B&R X20BT9400 Bus Transmitter Module

Product Description

The B&R X20BT9400 is an X2X Link Bus Transmitter Module designed for the B&R X20 I/O System. It is used to expand the X20 system by connecting X67 remote I/O modules through the X2X Link communication network, enabling flexible distributed I/O expansion in industrial automation applications.

The module also provides power supply for internal I/O modules and integrated X67 system power supply, allowing X67 modules to be connected without requiring a separate X67 power supply module.

Detailed Specifications

Parameter	Specification
Manufacturer	B&R Industrial Automation
Model	X20BT9400
Product Type	Bus Transmitter Module
Series	X20 I/O System
Communication Interface	X2X Link
Function	X20 to X67 system expansion
X2X Link Segment Length	Up to 100 m
Input Voltage	24 VDC (-15% / +20%)
X67 Link Power Supply	24 VDC
X67 Modules Supported	Up to 8 modules (horizontal mounting)
Internal I/O Power Supply	Supported
Power Consumption (Bus)	0.5 W
Power Consumption as Bus Transmitter	0.1 W
Additional Supply Module Consumption	0.6 W
Protection Rating	IP20
Mounting	B&R X20 Bus System
Installation Position	Rightmost slot only
Terminal Block	X20TB12
Bus Module	X20BM11 / X20BM15

Advantages & Features

Enables seamless expansion from X20 to X67 I/O systems
Uses B&R X2X Link high-speed communication technology
Supports distributed remote I/O architecture
Provides integrated power supply for X67 modules
Eliminates the need for an additional X67 power supply module in many configurations
Supports short-circuit and overload protection
Built-in LED indicators for:
- X2X Link communication status
- Module operating status
- Error diagnostics
Compact modular design for control cabinet installation
