B&R X20BR9300 Bus Receiver Module

Product Description

The B&R X20BR9300 is an X2X Link Bus Receiver Module designed for the B&R X20 I/O System. It is used to connect the X20 I/O system to the X2X Link communication network, enabling distributed I/O expansion and high-speed data exchange in industrial automation applications.

The module provides power supply for both the X2X Link bus and internal I/O modules, with electrical isolation between the supply circuits. It supports redundant X2X Link power supply configurations for increased system reliability.

Detailed Specifications

Advantages & Features

• Connects B&R X20 I/O system with X2X Link networks
• Provides power supply for X2X Link and internal I/O modules
• Supports redundant power supply operation
• Electrical isolation between supply and communication circuits
• Built-in overload monitoring and diagnostics
• LED indicators for:
  • Module status
  • X2X Link communication
  • Overload condition
• Compact modular design for industrial control cabinets
• Reliable operation in distributed automation systems

Applications

• B&R X20 PLC Systems
• Distributed Remote I/O Networks
• Factory Automation Equipment
• Machine Control Systems
• Packaging Machinery
• Robotics and Motion Control Systems
• Industrial Production Lines
• Process Automation Systems

Precautions

• Install the module only in the far left slot of the X20 system.
• Verify compatibility with the X20 controller and bus modules.
• Use the correct terminal block (X20TB12).
• Confirm 24 VDC power supply polarity and voltage.
• Check X2X Link wiring and network configuration before operation.
• Disconnect power before installation or replacement.
