B&R X20AO4622 Analog Output Module

Product Description

The B&R X20AO4622 is a 4-channel Analog Output Module designed for the B&R X20 I/O System. It provides high-precision analog output signals for controlling industrial devices such as variable speed drives, proportional valves, actuators, and other analog-controlled equipment.

The module supports both voltage output (±10 V) and current output (0–20 mA / 4–20 mA) through different terminal connections. It features 13-bit digital-to-analog conversion resolution, fast conversion time, output protection, and diagnostic functions for reliable industrial automation applications.

Detailed Specifications

Parameter	Specification
Manufacturer	B&R Industrial Automation
Model	X20AO4622
Product Type	Analog Output Module
Series	X20 I/O System
Output Channels	4 Analog Outputs
Output Signal	±10 V / 0–20 mA / 4–20 mA
Output Type	Voltage / Current Output
Resolution	13-bit digital converter
Conversion Time	300 μs for all outputs
Voltage Output Range	±10 V
Current Output Range	0–20 mA / 4–20 mA
Voltage Load	≥1 kΩ
Current Load	Max. 600 Ω
Output Current	Max. 10 mA (>5 V voltage output)
Output Protection	Short-circuit protection
Output Filter	First-order low-pass filter, 10 kHz
Nonlinearity	<0.007%
Isolation Voltage	500 V between channel and bus
Bus Power Consumption	0.01 W
Internal I/O Power Consumption	1.8 W (Rev. ≥J0)
Protection Rating	IP20
Mounting	B&R X20 Bus System
Terminal Block	X20TB12
Bus Module	X20BM11 / X20BM15
