B&R X20AI2622 Analog Input Module

Product Description

The B&R X20AI2622 is a 2-channel Analog Input Module designed for the B&R X20 I/O System. It is used to acquire and process analog signals from industrial sensors and transmitters, supporting both voltage signals (±10 V) and current signals (0–20 mA / 4–20 mA).

The module features a 13-bit analog-to-digital conversion resolution, configurable input filtering, differential inputs, and diagnostic functions, making it suitable for precise measurement applications in industrial automation systems.

Detailed Specifications

Parameter	Specification
Manufacturer	B&R Industrial Automation
Model	X20AI2622
Product Type	Analog Input Module
Series	X20 I/O System
Input Channels	2 Analog Inputs
Input Signal	±10 V / 0–20 mA / 4–20 mA
Input Type	Differential Input
Resolution	13-bit (including sign)
Conversion Time	300 μs for all inputs
Voltage Input Range	±10 V
Current Input Range	0–20 mA / 4–20 mA
Maximum Input Voltage	±30 V
Maximum Input Current	±50 mA
Input Impedance	20 MΩ (Voltage mode)
Input Filter	Third-order low-pass filter, 1 kHz cutoff
Data Format	INT
Isolation	Channel-to-bus isolation
Bus Power Consumption	0.01 W
Internal I/O Power Consumption	0.8 W
Protection Rating	IP20
Mounting	B&R X20 Bus System
Terminal Block	X20TB06 / X20TB12
Bus Module	X20BM11 / X20BM15
