B&R 8V1090.00-2 ACOPOS Servo Drive (Not standalone power supply module)

Overview

Key Specifications

1. Power Rating

• 3-phase input: 400–480 VAC ±10%
• Rated output: 4kW, continuous 8.8A / peak 24A
• Built-in line filter & integrated braking resistor

2. Hardware & Expansion

• 4 slots for optional plug-in modules (POWERLINK, encoder, digital I/O cards)
• Electronic safe restart inhibit for machine safety
• All pluggable wiring terminals for fast installation

3. Environment & Certifications

• IP20 cabinet mounting, operating temp 0–50°C
• CE, UL, UKCA certified, conformal coated PCB optional

4. Communication

• Support POWERLINK, CAN, EnDat encoder interfaces via add-on modules

Core Functions

1. Closed-loop position/speed/torque control for servo motors
2. Fast dynamic response for packaging, printing and machine tool axes
3. Built-in brake circuit for rapid motor deceleration
4. Full channel fault diagnosis, overvoltage/overcurrent/short-circuit protection
5. Real-time synchronization with B&R Automation Studio PLC
