B&R 8EI4X5HWT10.0500-1 ACOPOS P3 3-Axis Servo Drive

Overview

Key Specifications

1. Power: 3×200–480 VAC input, 4.5 A continuous current per axis, max 10 kVA total load
2. Mounting: Wall-mounted type, IP20 cabinet installation; dimensions 374×66×258.5 mm, weight 4 kg
3. Feedback: Built-in multi-standard encoder port (EnDat, incremental, resolver compatible)
4. Digital I/O: Isolated 24VDC fast digital inputs, microsecond-level response for limit & home signals
5. Environment: Operating temp 0–55°C, conformal coated PCB, 5–85% non-condensing humidity
6. Communication: POWERLINK real-time industrial bus, supports dynamic node allocation

Core Functions

1. Drive up to 3 servo axes simultaneously for multi-axis synchronous positioning
2. Receive encoder feedback to realize closed-loop high-precision motion control
3. Process limit switches, homing sensors via fast isolated digital inputs
4. Integrated hardware safety circuits for safe stop, overcurrent/overvoltage/short-circuit protection
5. Real-time axis status diagnosis, fault code upload to Automation Studio
