B&R 5AP920.1505-K46 Automation Panel

Product Overview

Brand: B&R (Bernecker & Rainer)
Series: Automation Panel 900
Model: 5AP920.1505-K46
Product Type: Industrial HMI / Automation Panel
Function: The B&R 5AP920.1505-K46 is a 15-inch industrial operator panel designed for machine visualization, operator control, and industrial PC applications. It provides a high-resolution TFT display, resistive touch screen, USB interfaces, and supports Automation Panel Link technology for connection with B&R industrial PCs.

Technical Specifications

Display Specifications

• Display Type: TFT Color LCD
• Screen Size: 15 inch (381 mm)
• Resolution: XGA 1024 × 768 pixels
• Colors: 16.7 million colors
• Contrast Ratio: 1000:1
• Backlight Type: LED
• Brightness: 350 cd/m²
• Backlight Life: Approx. 70,000 hours
• Viewing Angle:
  • Horizontal: ±85°
  • Vertical: ±85°

Touch Screen

• Touch Technology: Analog Resistive Touch
• Controller: Serial 12-bit touch controller
• Touch Type: Industrial touchscreen
• Application: Operator input, parameter adjustment, machine control

Interfaces

USB Interface

• Quantity: 3 × USB 2.0 Type A
• Data Rate:
  • Low speed: 1.5 Mbps
  • Full speed: 12 Mbps
  • High speed: 480 Mbps
• Maximum Current: 500 mA per port

Display Communication

• Supports:
  • Automation Panel Link SDL
  • DVI interface (depending on installed module)
  • Touch communication
  • USB data transmission

Electrical Specifications

• Supply Voltage: 24 VDC ±25%
• Rated Current: Max. 3.2 A
• Typical Power Consumption: Approx. 24 W
• Maximum Power Consumption:
  • 31 W standard
  • 41 W with USB devices
• Electrical Isolation: Yes

Mechanical Specifications

• Mounting: Panel mounting
• Protection Rating:
  • Front: IP65
  • Rear: IP20 (with proper panel link installation)
• Cooling: Fan-free operation
• Dimensions:
  • Width: 435 mm
  • Height: 330 mm
  • Depth: 54 mm
• Weight: Approx. 5.1 kg

Advantages & Features

High-Quality Industrial Display

Provides clear visualization with a 15-inch XGA TFT screen and excellent viewing angles, suitable for machine operation environments.

Reliable Touch Operation

The resistive touchscreen supports accurate operation even in industrial environments where operators may wear gloves.

Flexible Communication Expansion

Supports Automation Panel Link modules, allowing connection with B&R industrial PCs and automation controllers.

Fanless Industrial Design

Fan-free construction reduces maintenance requirements and improves long-term reliability.

Space-Saving Installation

Slim 54 mm depth design allows installation in compact control cabinets.

Durable Protection

Front IP65 protection provides resistance against dust and water spray for industrial applications.

Typical Applications

• Industrial HMI systems
• Factory automation equipment
• CNC machine tools
• Packaging machinery
• Robotics systems
• Production line monitoring
• Process control systems
• Industrial PC visualization systems
• Machine operator stations

Precautions

• Confirm compatibility with the B&R Automation Panel 900 system before installation.
• Ensure 24VDC power supply polarity is correct.
• Use suitable SDL/DVI communication modules and cables.
• Avoid excessive impact or pressure on the touchscreen surface.
• Keep ventilation around the panel installation area.
• Protect connectors from dust and moisture.
• Backup HMI configuration data before replacement.
• Disconnect power before maintenance.
