B&R 5AP1120.1043-C01 Industrial Panel Module

Item NO.:
5AP1120.1043-C01
Payment:
T/T
Price:
$1350
Product Origin:
AUSTRIA
Color:
NEW
Product weight:
0.09KG
Lead Time:
In stock

- B&R 5AP1120.1043-C01 Automation Panel Display Module

  Overview

  It is a 10.4-inch separate display touch unit from B&R AP1000 Automation Panel series, not an integrated controller panel. It needs to connect to PPC industrial panel PC / link communication module for operation, used as industrial HMI operator terminal for machine monitoring and operation. Suffix C01 stands for customized coating/conformal coated version for harsh environment.

  Key Specifications

  1. Display & Touch

  Screen: 10.4" color TFT LCD, VGA resolution 640×480 (4:3)

  Color depth: 16.7 million colors, contrast ratio 900:1

  LED backlight: Adjustable brightness 22.5–450 cd/m², half-lifetime 70,000 hours

  Touch: AMT analog resistive single touch, 12-bit serial touch controller, light transmittance 81%

  View angle: 80° horizontal / vertical

  2. Hardware & Interface

  Front panel built-in USB 2.0 Type-A port for program upload, U disk data storage

  Dedicated internal serial video/touch interface, matched with PPC900/PPC2100/PPC3100 panel PC or link modules

  Power supply: 24VDC input

  Mounting: Cabinet flush panel installation, landscape layout

  3. Environmental & Protection

  Front face IP65 / UL Type 4X waterproof dustproof; rear side IP20

  Operating temperature: 0 ~ +50°C, storage -20 ~ +70°C

  Model C01: PCB conformal coated version, anti-humidity, anti-corrosion for dusty/oily workshop

  Certifications: CE, UKCA, cULus, HazLoc Class I Div.2 hazardous location certification

  4. Mechanical

  Aluminum alloy housing, RAL7024 dark gray frame

  Overall dimension: 323mm(W) × 260mm(H), weight ~2.8kg

  Core Functions

  Industrial visualization: Display real-time production data, axis status, alarm information, parameter recipe screens

  Touch operation: Modify setpoints, trigger manual actions, acknowledge equipment faults

  Local data access: Front USB supports exporting production logs, backing up HMI project files

  Independent display terminal: Separated from main controller, flexible installation on machine door/control cabinet

  Long-term stable operation for harsh industrial workshop via conformal coated circuit board

  Compatibility

  Match B&R PPC900, PPC2100, PPC2200, PPC3100 series Panel PC and AP link communication modules; interchangeable with standard model 5AP1120.1043-000 (C01 is coated variant)

  Applications

  HMI spare display unit for packaging machines, textile equipment, printing presses, CNC machine tools, and hazardous industrial production lines requiring anti-corrosion circuit boards.
