B&R 4PP065.0571-X74F Power Panel 65 Integrated HMI Controller

Overview

Key Specifications

1. Display & Touch

• Screen: 5.7" color TFT LCD, QVGA resolution 320×240
• Brightness: 500 cd/m², backlight half-life 50,000 hours, contrast ratio 350:1B& R Industrial Automation
• Touch: Analog resistive touchscreen (12-bit controller), 10 physical side function keys
• View angle: Horizontal ±60°, vertical up 65° / down 50°; supports screen rotation

2. Hardware Performance

• CPU: Geode LX800 500MHz 32-bit x86 processor
• Memory: 128MB DDR SDRAM + 232kB SRAM
• Storage: 4MB built-in flash for firmware + Type I CompactFlash expansion slot
• Backup battery: External replaceable lithium battery, 4-year service life

3. Communication Interfaces

• 1× 10/100Mbps Ethernet
• 1× POWERLINK real-time bus (X2X Link)
• 2× USB 2.0 host ports
• Supports Modbus, RS485, PROFIBUS via expansion modules

4. Electrical & Environmental

• Power supply: 24VDC input
• Protection: Front panel IP65 (dustproof/waterproof), rear IP20
• Operating temp: 0°C ~ +50°C; storage -20°C ~ +70°C
• Weight: 0.75kg, panel cutout mounting
• Certifications: CE, UL, EAC, UKCA

Core Functions

1. Dual HMI & Control

   Run operation screen visualization, recipe management, alarm logging, plus independent PLC logic, motion sequence control locally.
2. Real-time Motion Sync

   Connect ACOPOS servo drives via POWERLINK for multi-axis positioning, synchronous motion.
3. Field Device Data Exchange

   Communicate with X20 I/O modules, sensors and third-party equipment over Ethernet/serial buses.
4. Data Storage & Upload

   Store production data, program backups on CF card; upload/download projects via USB/Ethernet.
5. Full System Diagnostics

   Built-in status LEDs for power, bus communication, CF card and system fault alerts.
