B&R 4PP065.0571-P74F Operator Panel

Product Overview

Brand: B&R (Bernecker & Rainer)
Series: Power Panel 65 (PP65)
Model: 4PP065.0571-P74F
Product Type: Industrial Operator Panel / HMI Controller
Function: The B&R 4PP065.0571-P74F is a compact Power Panel 65 HMI operator panel integrating a color TFT display, resistive touchscreen, function keys, PLC controller functions, Ethernet, POWERLINK, USB interfaces, and CompactFlash storage. It is designed for machine operation, visualization, and automation control applications.

Technical Specifications

General Data

• Brand: B&R
• Model: 4PP065.0571-P74F
• Series: Power Panel 65
• Type: HMI Operator Panel with Integrated Controller
• Display Size: 5.7 inch
• Display Type: TFT Color LCD
• Touch Screen: Analog Resistive Touch
• Function Keys: 10 keys
• Protection Rating: Front IP65
• Installation: Panel mounting
• Weight: Approx. 0.75 kg

Display Specifications

• Screen Size: 5.7 inch (144 mm diagonal)
• Resolution: QVGA 320 × 240 pixels
• Display Colors: 262,144 colors
• Contrast Ratio: 350:1
• Brightness: 500 cd/m²
• Backlight Life: Approx. 50,000 hours
• Touch Technology: Analog resistive
• Touch Controller: 12-bit B&R controller
• Viewing Angle:
  • Horizontal: ±60°
  • Vertical: +65° / -50°

Controller Specifications

• Processor: AMD Geode LX800 32-bit x86
• Clock Frequency: 500 MHz
• RAM: 128 MB DDR SDRAM
• User SRAM: 232 kB
• Firmware Flash: 4 MB
• Real-Time Clock: Battery backed
• Watchdog: Integrated MTCX watchdog
• Cooling: Passive cooling via heatsink
• CompactFlash Slot: 1 × Type I

Communication Interfaces

Ethernet

• Quantity: 1 port
• Interface: RJ45
• Speed: 10/100 Mbps
• Controller: Intel 82551ER
• Application: PLC programming, HMI communication, industrial networking

POWERLINK

• Quantity: 1 port
• Protocol: POWERLINK V1/V2
• Speed: 100 Mbps
• Interface: Shielded RJ45
• Application: Real-time communication with B&R automation systems

USB

• Quantity: 2 × USB 2.0 Type A
• Speed:
  • Low speed: 1.5 Mbps
  • Full speed: 12 Mbps
  • High speed: 480 Mbps
• Maximum Current: 500 mA per port

Electrical Specifications

• Supply Voltage: 24 VDC ±25%
• Rated Current: 0.45 A
• Inrush Current: Max. 2.8 A
• Typical Power Consumption: 10 W
• Electrical Isolation: No

Mechanical Specifications

• Housing Material: Polyester
• Dimensions:
  • Width: 203 mm
  • Height: 145 mm
  • Depth: 56.5 mm
• Front Protection: IP65
• Rear Protection: IP20

Advantages & Features

Integrated HMI + Controller

Combines operator interface and PLC control functions in one compact unit, reducing cabinet space and system complexity.

Reliable Industrial Touch Operation

The resistive touchscreen supports accurate operation in industrial environments, including glove operation.

Real-Time POWERLINK Communication

Provides high-speed communication with B&R PLCs, drives, and distributed I/O systems.

Compact Machine Installation

The slim Power Panel 65 design is suitable for small and medium-sized automation equipment.

Flexible Storage Expansion

Supports CompactFlash memory for application programs, recipes, and data storage.

Durable Industrial Design

Front IP65 protection allows use in demanding factory environments.

Typical Applications

• Machine automation systems
• Packaging machinery
• CNC equipment
• Robotics systems
• Production lines
• Process control equipment
• Industrial monitoring systems
• B&R PLC control applications

Compatible Accessories

• 0TB103.91 — 24VDC 3-pin cage clamp terminal block
• CompactFlash memory cards
• PP65 interface modules (CAN, PROFIBUS, RS232/RS485 options)

Precautions

• Confirm 24VDC power polarity before connection.
• Ensure correct CompactFlash application memory installation.
• Avoid impact or excessive pressure on the touchscreen.
• Check POWERLINK network configuration before startup.
• Use proper grounding and EMC protection.
• Keep ventilation around the panel area.
• Disconnect power before replacement or maintenance.
