Product Overview

The B&R 4PP015.E420-101 is a Power Panel HMI Controller designed for industrial automation applications. It integrates operator interface, PLC control functions, digital I/O, and communication interfaces in a compact unit, providing efficient machine control and visualization solutions.

Main Specifications

• Manufacturer: B&R Automation
• Model: 4PP015.E420-101
• Product Type: HMI Panel / Power Panel Controller
• Display Type: Monochrome LCD with LED backlight
• Display Resolution: 4 × 20 characters
• Power Supply: 24 VDC
• Power Consumption: Max. 6 W
• Memory:
  • System PROM: 448 kB FlashPROM
  • User PROM: 1984 kB FlashPROM
  • User RAM: 300 kB SRAM
• Communication Interfaces:
  • RS232
  • CAN Interface
• Digital Inputs: 16 × 24 VDC inputs
• Digital Outputs: 16 × 24 VDC outputs, 0.5 A
• Protection Rating: IP65 (front)
• Dimensions: 153 × 120 × 46.1 mm
• Weight: Approx. 0.5 kg

Advantages & Features

• Integrated HMI and PLC control functions
• Compact design for limited installation space
• Reliable operation in industrial environments
• Supports CAN and serial communication
• Built-in digital I/O for flexible control applications
• IP65 front protection for harsh environments
• Easy maintenance with LED status indicators

Applications

• Industrial automation systems
• Machine control equipment
• Packaging machinery
• Manufacturing production lines
• Process monitoring systems
• Motion control applications

Important Notes

• Confirm hardware compatibility before installation
• Use a stable 24VDC power supply
• Check communication parameters before operation
• Protect the LCD panel from impact and excessive vibration
• Ensure correct wiring of I/O terminals
