B&R 3NC154.60-2 Control Module

Product Description

B&R 3NC154.60-2 is a 2005 Series 3-Axis Positioning Control Module designed for motion control applications. It provides precise axis positioning control with encoder feedback, analog outputs, digital inputs, and relay output functions for industrial automation systems.

Specifications

• Brand: B&R (Bernecker + Rainer)
• Model: 3NC154.60-2
• Series: System 2005 / NC154
• Product Type: Positioning Control Module / Motion Control Module
• Axis Control: 3 Axes
• Encoder Input:
  • Incremental encoder 5V input
  • SSI absolute encoder input
• Encoder Input Frequency: Up to 150 kHz
• Analog Output: ±10V, 12-bit resolution
• Encoder Power Supply: 5VDC / 24VDC
• Digital Inputs: 4 × 24VDC inputs
• Trigger Input: 24VDC sink input
• Relay Output: 24VAC / 24VDC, 1A
• Mounting: B&R System 2005 rack installation

Advantages & Features

• Supports 3-axis precision motion control
• Compatible with incremental and SSI absolute encoders
• High-speed encoder signal processing
• Provides accurate positioning and feedback control
• Integrated analog and digital I/O functions
• Reliable performance for industrial automation applications
• Compact modular design for control cabinets

Applications

• CNC machinery
• Robotics and motion control systems
• Packaging equipment
• Semiconductor manufacturing equipment
• Automated production lines
• Precision positioning systems

Notes

• Confirm compatibility with B&R System 2005 controllers before installation
• Terminal blocks must be purchased separately if required
• Check encoder type and wiring configuration before operation
• Ensure correct power supply and grounding
• Configure motion parameters before commissioning
