B&R 3IF797.9-1 Interface Module

Product Description

B&R 3IF797.9-1 is an aPCI Interface Module designed for B&R automation systems. It provides multiple communication interfaces including RS232, CAN bus, and X2X Link Master, enabling flexible communication expansion for B&R controllers and industrial automation equipment.

Specifications

• Brand: B&R (Bernecker + Rainer)
• Model: 3IF797.9-1
• Product Type: Interface / Communication Module
• Module Type: aPCI Interface Module
• Interfaces:
  • 1 × RS232 Interface
  • 1 × CAN Bus Interface
  • 1 × X2X Link Master Interface
• RS232 Communication Speed: Max. 115.2 kbit/s
• CAN Bus Speed: Max. 500 kbit/s
• CAN Bus Distance: Up to 1000 m
• X2X Link Distance: Max. 100 m between stations
• Electrical Isolation: Supported between communication interfaces
• Protection Class: IP20
• Operating Temperature: 0 to 60°C
• Mounting: B&R aPCI slot installation

Advantages & Features

• Multi-interface communication expansion for B&R controllers
• Supports RS232, CAN bus, and X2X Link communication
• Electrical isolation improves system stability and reliability
• Fast and reliable industrial data exchange
• Flexible integration with automation networks
• Compact design for control cabinet installation
• Suitable for complex industrial control systems

Applications

• Industrial automation systems
• B&R PLC control systems
• Machine control equipment
• Motion control systems
• Remote I/O communication
• Factory production lines
• Process automation systems

Notes

• Confirm compatibility with the B&R controller and aPCI slot before installation
• Check communication parameters before operation
• Use proper terminal blocks and wiring accessories
• Ensure correct grounding and shielding for communication cables
•
