Allen-Bradley MPL-B1530U-VJ42AA MP-Series Servo Motor

Product Overview

The Allen-Bradley MPL-B1530U-VJ42AA is a Kinetix MP-Series Low-Inertia Brushless AC Servo Motor designed for high-performance motion control applications. It belongs to the MP-Series Premium Permanent Magnet Rotary Servo Motors and is commonly used with Kinetix servo drives in machine automation, packaging, material handling, and precision manufacturing systems.

The motor features a 400V voltage class, 63 mm frame size, 3-inch magnetic stack, and a high-resolution multi-turn absolute encoder, providing precise position, speed, and torque control.

Main Specifications

• Manufacturer: Allen-Bradley (Rockwell Automation)
• Model: MPL-B1530U-VJ42AA
• Series: MP-Series Low-Inertia Servo Motor
• Product Type:
  • AC Servo Motor
  • Brushless Permanent Magnet Servo Motor
  • Rotary Servo Motor
• Voltage Class: 400 VAC
• Frame Size: 63 mm
• Magnetic Stack Length: 76.2 mm (3 in.)
• Rated Speed: 7000 rpm
• Rated Output Power: Approximately 0.39 kW
• Rated Torque: Approximately 0.9 N·m
• Feedback: High-resolution multi-turn absolute encoder (128 Sin/Cos, Hiperface)
• Shaft: Keyed shaft
• Shaft Seal: None
• Brake: No brake
• Mounting Flange: IEC Metric
• Protection Rating: IP65 housing

Technical Functions

The MPL-B1530U-VJ42AA provides:

• High-precision position control
• Closed-loop speed control
• Dynamic torque control
• Smooth acceleration and deceleration
• High-speed motion control
• Encoder feedback for accurate positioning

Working principle:

Motion Controller → Kinetix Servo Drive → MPL Servo Motor → Mechanical Motion

Features & Advantages

• Original Allen-Bradley MP-Series servo motor
• Compact low-inertia rotor for fast dynamic response
• High-resolution absolute encoder
• Brushless maintenance-free design
• High power-to-size ratio
• IP65 enclosure for industrial environments
• Excellent positioning accuracy and repeatability
• Designed for demanding automation applications

Applications

Used in:

• Packaging machinery
• CNC equipment
• Material handling systems
• Robotics
• Printing machinery
• Semiconductor equipment
• Automated assembly lines

Typical applications:

• Servo axis control
• Precision positioning
• High-speed indexing
• Automated production systems
