Allen-Bradley ILX69-PBM PROFIBUS DP Master Communication Module

Allen-Bradley ILX69-PBM PROFIBUS DP Master Communication Module

Product Overview

The Allen-Bradley ILX69-PBM is a PROFIBUS DP Master Communication Module developed by ProSoft Technology for CompactLogix 1769 PLC systems. It enables seamless integration between CompactLogix controllers and PROFIBUS DP slave devices, supporting both DP-V0 and DP-V1 communication for high-speed industrial data exchange.

Main Specifications

• Manufacturer: Allen-Bradley / ProSoft Technology
• Model: ILX69-PBM
• Product Type: PROFIBUS DP Master Communication Module
• Compatible Platform: CompactLogix 1769
• Communication Protocol: PROFIBUS DP-V0 / DP-V1
• PROFIBUS Speed: 9.6 kbps to 12 Mbps
• Backplane Interface: 1769 CompactLogix
• Configuration: ProSoft Configuration Manager
• Memory: 8 MB SDRAM, 16 MB Flash
• Diagnostics: Ethernet Port with LED Status Indicators
• PROFIBUS Connector: 9-pin D-Sub
• Mounting: DIN Rail / Control Cabinet Installation

Advantages & Features

• Supports PROFIBUS DP-V0 and DP-V1 communication
• High-speed and reliable industrial networking
• Easy integration with CompactLogix PLC systems
• Built-in Ethernet diagnostics and configuration
• Fast commissioning with AutoScan technology
• Industrial-grade design for continuous operation

Applications

• Factory Automation
• PLC Communication Networks
• Process Control Systems
• Manufacturing Equipment
• Material Handling Systems
• Power and Utility Applications

Important Notes

• Verify PLC compatibility before installation
• Configure PROFIBUS parameters correctly
• Use certified PROFIBUS cables and connectors
• Ensure proper grounding and network termination
• Disconnect power before wiring or maintenance
