Allen-Bradley 56RF-TR-4040 RFID Reader (Transceiver)



Product Overview

The Allen-Bradley 56RF-TR-4040 is a high-frequency (HF) industrial RFID transceiver used for track-and-trace identification in automation systems.

It belongs to Rockwell’s Bulletin 56RF RFID system, designed for reading/writing RFID tags in production lines.

Key Specifications (verified)

• Brand: Allen-Bradley (Rockwell Automation)
• Series: 56RF RFID System
• Model: 56RF-TR-4040
• Type: RFID transceiver / reader head
• Frequency: 13.56 MHz (HF RFID)
• Standard: ISO 15693 / ISO 18000-3
• Size: 40 × 40 mm square head
• Function: Read/write RFID tag data in industrial environments
• Communication: IO-Link / EtherNet/IP via interface modules (system dependent)
• Power supply: typically 24 VDC (industrial sensor class)
• Country of origin: Japan

What It Does (Simple Explanation)

This device works like an industrial “identity scanner”:

1. RFID tag is attached to product / fixture / pallet
2. Reader emits 13.56 MHz electromagnetic field
3. Tag is powered and returns its ID/data
4. PLC receives data (via IO-Link / Ethernet system)
5. System tracks product automatically

Key Features

• High-frequency 13.56 MHz RFID technology
• Compact 40×40 mm industrial head
• ISO 15693 compatible (industrial standard tags)
• Read/write capability (not only reading ID)
• Designed for harsh factory environments
• Integrates with Rockwell PLC systems

Advantages

• Accurate part tracking in production lines
• No manual scanning required
• Strong integration with CompactLogix / ControlLogix systems
• Reliable for metal fixture / assembly tracking
• Supports automated quality traceability

Applications

• Automotive assembly tracking
• Production line workpiece identification
• Tool & fixture management
• Conveyor tracking systems
• Warehouse and logistics automation
• Smart manufacturing (Industry 4.0)
