Allen-Bradley 5094-RTB3T Removable Terminal Block

Allen-Bradley 5094-RTB3T Removable Terminal Block

Product Overview

The Allen-Bradley 5094-RTB3T is a FLEX 5000 I/O CJC Screw Removable Terminal Block (RTB) designed for FLEX 5000 I/O modules. It includes an integrated Cold Junction Compensation (CJC) thermistor for thermocouple temperature measurement applications, providing accurate temperature signal connections in industrial control systems.

Main Specifications

• Manufacturer: Allen-Bradley (Rockwell Automation)
• Model: 5094-RTB3T
• Product Type: Removable Terminal Block
• Series: FLEX 5000 I/O
• Terminal Type: Screw Terminal
• Special Function: Built-in CJC Thermistor
• Compatible System: FLEX 5000 I/O Modules
• Input Rating: 100 mA @ 10 VDC
• Sensor Source Voltage Output: 1.8 A @ 24 VDC
• Sensor Actuator Power: 10 A @ 18–32 VDC
• Isolation Voltage: 250 VAC continuous
• Wire Type: Solid / Stranded Copper Wire
• Mounting: FLEX 5000 Terminal Base Assembly
• Country of Origin: Singapore

Advantages & Features

• Integrated CJC thermistor improves thermocouple measurement accuracy
• Removable design allows quick installation and maintenance
• Screw terminal connection provides secure field wiring
• Designed specifically for FLEX 5000 distributed I/O systems
• Supports reliable analog and temperature signal connections
• Industrial-grade construction for long-term operation

Applications

• Temperature monitoring systems
• Process automation
• Factory automation equipment
• PLC control cabinets
• Industrial heating and cooling systems
• Manufacturing production lines

Important Notes

• Confirm compatibility with the correct FLEX 5000 I/O module before installation
• Ensure thermocouple wiring polarity is correct
• Use proper grounding and shielding methods
• Check terminal tightening torque
• Disconnect power before replacement or maintenance
