Allen-Bradley 5094-RTB3I Removable Terminal Block

Product Overview

The Allen-Bradley 5094-RTB3I is an isolated screw-type Removable Terminal Block (RTB) designed for the FLEX 5000 I/O system. It is used as the field wiring interface for FLEX 5000 I/O modules, providing convenient connection and replacement of field-side wiring without removing the complete I/O module.

The 5094-RTB3I features isolated I/O channels, helping protect field devices and control systems from electrical interference and unwanted voltage interaction.

Main Specifications

• Manufacturer: Allen-Bradley (Rockwell Automation)
• Model: 5094-RTB3I
• Series: FLEX 5000 I/O
• Product Type:
  • Removable Terminal Block (RTB)
  • Isolated Screw Terminal Block
  • FLEX 5000 I/O Accessory
• Terminal Type: Screw-type terminal
• Isolation Type: Channel-to-channel / channel-to-chassis isolation
• Input/Output Rating: Max. 2 A @ 32 VDC
• Sensor Actuator Power Rating: Max. 10 A @ 18…32 VDC
• Wire Type: Solid or stranded copper wire
• Wire Size: 22…14 AWG
• Mounting: FLEX 5000 I/O terminal base assembly

Technical Specifications

Functions

The 5094-RTB3I provides:

• Field wiring connection for FLEX 5000 I/O modules
• Quick module replacement without rewiring
• Electrical isolation between I/O channels
• Connection for sensors, actuators, and field devices
• Organized wiring inside industrial control cabinets

Working principle:

Field Devices → 5094-RTB3I Terminal Block → FLEX 5000 I/O Module → PLC Controller

Features & Advantages

• Original Allen-Bradley FLEX 5000 accessory
• Isolated screw terminal design
• Simplifies installation and maintenance
• Reduces wiring downtime during module replacement
• Supports industrial sensor and actuator connections
• Improves system reliability through channel isolation
• Suitable for demanding automation environments

Applications

Used in:

• Industrial automation systems
• Machine control panels
• Factory production lines
• Process automation equipment
• Packaging machinery
• Material handling systems

Typical applications:

• Digital input/output wiring
• Sensor connection
• Actuator control
• Distributed I/O systems

Compatible Equipment

Commonly used with:

• Allen-Bradley FLEX 5000 I/O modules
• 5094 series I/O terminal base assemblies
• CompactLogix 5380 controllers
• ControlLogix EtherNet/IP systems
• Studio 5000 Logix Designer
