Allen-Bradley 5069-OA16 Digital Output Module





Product Overview

The Allen-Bradley 5069-OA16 is a 16-channel AC digital output module in the Compact 5000 I/O / CompactLogix 5380 system.

It is used to switch AC loads such as relays, solenoids, contactors, and indicator lamps.

Key Specifications (confirmed)

• Brand: Allen-Bradley (Rockwell Automation)
• Series: Compact 5000 I/O
• Model: 5069-OA16
• Channels: 16 AC outputs
• Output Voltage: 85–264 VAC (120/240V nominal)
• Output Type: Triac (solid-state AC switching)
• Current Rating:
  • 0.5 A per channel
  • 4 A per module total
• Frequency: 47–63 Hz
• Isolation: basic isolation (~300V class)
• Platform: CompactLogix 5380 / GuardLogix 5380 / Compact 5000 I/O

Key Features

• 16-channel high-density AC switching output
• Solid-state triac output (no mechanical relay wear)
• Supports 120V / 240V AC industrial loads
• Built-in LED status indicators per channel
• Fast switching suitable for industrial automation
• Integrated diagnostics via Studio 5000

Working Principle

The PLC sends a digital command to the module:

• PLC = ON → triac conducts → AC load energized
• PLC = OFF → output stops conducting → load de-energized

Used for:

• Turning ON motors (via contactor coils)
• Driving solenoid valves
• Controlling AC indicators and heaters

Advantages

• No mechanical wear (solid-state switching)
• High channel density (16 outputs in one module)
• Reliable for repetitive switching applications
• Stable operation in industrial environments
• Easy diagnostics and LED status per channel
• Seamless integration with Rockwell PLC system

Applications

• Solenoid valve control
• Motor starter control (via contactors)
• Conveyor system actuators
• Industrial lighting systems
• Heating elements
• OEM machine automation
