Allen-Bradley 2711PC-T10C4D8 PanelView Plus Compact HMI

Product Overview

The Allen-Bradley 2711PC-T10C4D8 is a PanelView Plus 6 Compact Terminal (HMI) from Rockwell Automation. It is designed for operator interface applications, allowing users to monitor, control, and visualize industrial automation processes. The unit features a 10.4-inch color touchscreen display, Ethernet and serial communication, and 24V DC power input.

It is widely used with Allen-Bradley PLC systems such as CompactLogix, ControlLogix, and MicroLogix for machine operation, process monitoring, and industrial control applications.

Main Specifications

• Manufacturer: Allen-Bradley (Rockwell Automation)
• Model: 2711PC-T10C4D8
• Series: PanelView Plus 6 Compact
• Product Type:
  • Human Machine Interface (HMI)
  • Operator Interface Terminal
  • Touchscreen Display Terminal
• Display Size: 10.4 inch
• Display Type: Color Active Matrix TFT LCD
• Resolution: 640 × 480 pixels
• Input Type: Resistive Touch Screen
• Color Depth: 18-bit color graphics
• Brightness: 300 cd/m² (nits)
• Backlight: Replaceable CCFL backlight

Technical Specifications

Communication Functions

The 2711PC-T10C4D8 supports:

• Ethernet communication
• RS-232 serial communication
• RS-422 communication
• PLC data visualization
• Operator command input
• Alarm display
• Machine status monitoring

Working principle:

PLC Controller → Ethernet / Serial Communication → PanelView HMI → Operator Monitoring & Control

Features & Advantages

• Original Allen-Bradley PanelView Plus 6 Compact HMI
• Large 10.4-inch color touchscreen
• Reliable industrial-grade design
• Supports FactoryTalk View ME applications
• Easy integration with Rockwell PLC systems
• Compact installation depth for control cabinets
• Supports SD card data transfer
• Suitable for long-term industrial operation

Applications

Used in:

• Factory automation equipment
• CNC machines
• Packaging machinery
• Production lines
• Material handling systems
• Process control systems
• Industrial control panels

Typical applications:

• Machine operator interface
• Process visualization
• Alarm monitoring
• Recipe management
• Equipment status display

Compatible Equipment

Commonly used with:

• Allen-Bradley CompactLogix PLC
• Allen-Bradley ControlLogix PLC
• MicroLogix controllers
• FactoryTalk View Studio ME software
• EtherNet/IP automation systems
