Allen-Bradley 22F-A4P2N113 PowerFlex 40 AC Drive

Allen-Bradley 22F-A4P2N113 PowerFlex 40 AC Drive

Product Overview

The Allen-Bradley 22F-A4P2N113 is a PowerFlex 4M Adjustable Frequency AC Drive (VFD) from Rockwell Automation. It is designed for controlling the speed, torque, and operation of three-phase AC motors in industrial automation applications.

Note: The model is commonly referred to as a PowerFlex 40 AC Drive, but the exact catalog number 22F-A4P2N113 belongs to the PowerFlex 4M family.

Main Specifications

• Manufacturer: Allen-Bradley (Rockwell Automation)
• Model: 22F-A4P2N113
• Product Type:
  • Adjustable Frequency AC Drive
  • Variable Frequency Drive (VFD)
• Series:
  • PowerFlex 4M

Electrical Specifications

• Input Voltage:
  • 240 VAC
• Input Phase:
  • Single Phase
• Input Frequency:
  • 50/60 Hz
• Rated Output Current:
  • 4.2 A
• Output Power:
  • 0.75 kW
  • 1 HP
• Output Voltage:
  • 0–230 VAC
• Output Phase:
  • Three Phase
• Power Factor:
  • 0.98

Hardware Features

• Frame Size:
  • Frame A
• Enclosure:
  • IP20 / UL Open Type
• Mounting:
  • Panel Mount
  • DIN rail mounting support (Frame A/B)
• Display:
  • LED display
• Keypad:
  • Fixed digital keypad with potentiometer
• Internal Filter:
  • CE compliant EMC filter
• Brake:
  • No brake IGBT

Communication & Control

• Built-in Communication:
  • RS-485
• Control Method:
  • V/Hz control
  • Sensorless speed control
• Inputs/Outputs:
  • Digital inputs
  • Analog input
  • Relay output

Advantages & Features

• Compact design for small motor applications
• Reliable speed control for industrial AC motors
• Easy parameter setup through integrated keypad
• Built-in EMC filtering reduces electrical interference
• Supports RS-485 communication for automation integration
• Suitable for OEM machines and retrofit projects
• Provides motor overload protection and ramp control functions

Applications

• Conveyor systems
• Pumps and fans
• Packaging machinery
• Material handling equipment
• Small machine automation
• HVAC auxiliary drives
• Factory production equipment

Compatible Equipment

Commonly used with:

• Three-phase induction motors
• Industrial pumps
• Fans and blowers
• Machine tools
• PLC-controlled motor systems

Important Notes

• Confirm motor power and voltage before replacement.
• This drive requires a three-phase motor output, even though the input supply is single-phase 240VAC.
• Verify motor current does not exceed the drive’s 4.2A output rating.
• Install in a suitable enclosure if additional environmental protection is required.
• Disconnect power before wiring or maintenance.
