Allen-Bradley 2094-BC04-M03-S Kinetix Integrated Axis Module

Allen-Bradley 2094-BC04-M03-S Kinetix Integrated Axis Module

Product Overview

The Allen-Bradley 2094-BC04-M03-S is a Kinetix 6000 Integrated Axis Module (IAM) designed for high-performance servo motion control applications. It combines converter and inverter functions in one module and provides precise control of Allen-Bradley servo motors in demanding industrial automation systems. The module includes Safe Torque-Off (STO) functionality for enhanced machine safety.

Main Specifications

• Manufacturer: Allen-Bradley (Rockwell Automation)
• Model: 2094-BC04-M03-S
• Product Type: Integrated Axis Module (IAM)
• Series: Kinetix 6000
• Input Voltage: 360–480 VAC, 3 Phase
• Converter Rating: 28 kW / 42 A
• Inverter Output: 13.5 kW / 30 A
• Frequency: 47–63 Hz
• Safety Function: Safe Torque-Off (STO)
• Mounting: Panel Mount
• Control Platform: Logix-based motion control systems
• Country of Origin: Mexico

Advantages & Features

• High-performance servo motion control
• Integrated converter and inverter design saves cabinet space
• Supports precise position, velocity, and torque control
• Built-in Safe Torque-Off function improves machine safety
• Reliable operation for continuous industrial applications
• Easy integration with Allen-Bradley Kinetix motion systems
• Suitable for multi-axis coordinated motion control

Applications

• Industrial automation equipment
• CNC machinery
• Robotics and servo systems
• Packaging machines
• Material handling systems
• Semiconductor manufacturing equipment
• Precision motion control applications

Important Notes

• Verify compatibility with Kinetix 6000 system components before installation
• Confirm input voltage and motor specifications
• Configure motion parameters correctly before operation
• Ensure proper grounding and safety wiring
• Installation should be performed by qualified technicians
