Allen-Bradley 1769-OF8C/A Analog Output Module



Allen-Bradley 1769-OF8C/A Analog Output Module

Product Description
Allen-Bradley 1769-OF8C/A is a Compact I/O Analog Output Module designed for CompactLogix™ control systems. It provides 8-channel current output for precise actuator control and industrial process applications.

Technical Parameters

• Brand: Allen-Bradley
• Model: 1769-OF8C/A
• Product Type: Analog Output Module
• Series: Compact I/O 1769 Series
• Output Channels: 8 Channels
• Output Signal: 0…20 mA / 4…20 mA
• Resolution: 16-bit analog resolution
• Output Type: Single-ended current output
• Power Supply: 24V DC system power
• Isolation: 500V AC / 710V DC isolation test
• Mounting: DIN rail or panel mounting
• Communication: CompactLogix backplane communication

Advantages & Features

• High-precision 8-channel analog current output design
• Supports standard industrial 4–20 mA control signals
• Fast response and stable signal conversion
• Built-in protection against open circuit, short circuit and overvoltage
• Compact design saves installation space
• Easy integration with Allen-Bradley CompactLogix automation systems

Applications

• Industrial automation control systems
• Process control equipment
• Valve and actuator control
• Motor speed regulation systems
• Water treatment and energy management
• Factory production line automation

Notes

• Confirm controller compatibility before installation.
• Check output signal range before wiring.
• Use proper grounding and shielding for analog signals.
• Avoid incorrect wiring to prevent module damage.
