Allen-Bradley 1492-SP2D060 Series C Circuit Breaker

1. Product Description

The 1492-SP2D060 is a 2-pole, 6A, D-type trip characteristic miniature circuit breaker (MCB) from Allen-Bradley’s 1492-SP series. Designed for industrial and commercial applications, it provides overcurrent and short-circuit protection for electrical circuits, particularly those with high inductive loads like motors, transformers, and welding equipment .

2. Key Features

D-Type Trip Curve – Trips at 10–25 times the rated current (6A), making it ideal for high inrush current applications .
Dual-Terminal Design – Allows flexible wiring with up to four conductors (2 wires per terminal) .
Compact & Modular – DIN rail mountable (35mm) with a finger-safe IP20 rating .
High Durability – Resistant to shock, vibration, and extreme temperatures (-25°C to +55°C) .
Hot-Swappable – Supports live maintenance with optional accessories like auxiliary contacts .
Certifications – Complies with UL 489, IEC 60947-2, CE, CSA, and RoHS .

3. Technical Specifications

Parameter	Specification
Rated Current	6A
Poles	2P
Trip Curve	D-type (10–25× In)
Voltage Rating	277V AC / 480V AC / 96V DC
Breaking Capacity	10 kA
Mounting	DIN rail (35 mm)
Operating Temp.	-25°C to +55°C
Dimensions	88mm (D) × 35mm (L) × 75mm (W)
