Allen-Bradley 1489-M2C200 Miniature Circuit Breaker

Allen-Bradley 1489-M2C200 Miniature Circuit Breaker

Product Overview

The Allen-Bradley 1489-M2C200 is a Bulletin 1489-M Miniature Circuit Breaker (MCB) designed for industrial branch circuit protection. It provides reliable thermal-magnetic protection against overload and short-circuit conditions and is suitable for industrial control panels and automation equipment.

Main Specifications

• Manufacturer: Allen-Bradley (Rockwell Automation)
• Model: 1489-M2C200
• Product Type: Miniature Circuit Breaker (MCB)
• Series: Bulletin 1489-M
• Pole Configuration: 2 Pole
• Rated Current: 20 A
• Trip Curve: C Curve
• Rated Voltage:
  • 480Y/277 VAC (UL/CSA)
  • 400 VAC (IEC)
  • 96 VDC
• Frequency: 50/60 Hz
• Mounting Type: DIN Rail Mount
• Short Circuit Breaking Capacity: Up to 10 kA / 15 kA depending on standard
• Protection Type: Thermal Magnetic Protection
• Terminal Capacity: Up to 35 mm² conductor size

Advantages & Features

• Reliable overload and short-circuit protection
• Compact DIN rail mounting design
• Fast fault isolation to protect equipment
• C-trip curve suitable for industrial loads
• Compatible with industrial control panels and automation systems
• Supports auxiliary accessories for flexible applications
• High durability for continuous industrial operation

Applications

• Industrial control cabinets
• PLC power protection systems
• Factory automation equipment
• Motor control panels
• Machine building applications
• Power distribution systems
• Industrial electrical protection circuits

Important Notes

• Confirm rated voltage and current before installation
• Ensure correct DIN rail mounting and wiring
• Do not exceed the rated breaking capacity
• Select suitable cable size according to load requirements
• Installation should be performed by qualified personnel
