Allen-Bradley 100-C85D10 IEC Contactor





Product Overview

The Allen-Bradley 100-C85D10 is an IEC-rated 3-pole AC magnetic contactor from the Bulletin 100-C series. It is designed for switching and controlling motors, pumps, fans, compressors, and other industrial electrical loads in automation control systems.

Key Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Series: Bulletin 100-C IEC Contactor
• Model: 100-C85D10
• Product Type: AC Magnetic Contactor
• Main Poles: 3 NO (3-phase power contacts)
• Rated Current: 85 A (AC-3 motor duty)
• Maximum Operational Voltage: Up to 600 VAC class
• Coil Voltage: 110 VAC 50 Hz / 120 VAC 60 Hz
• Auxiliary Contacts: 1 NO auxiliary contact, 0 NC
• Connection Type: Screw terminals
• Mounting: Panel mounting / DIN rail installation with accessories
• Contact Type: IEC contactor

What It Does (Simple Explanation)

The contactor operates through an electromagnetic coil:

1. Control voltage energizes the coil.
2. The magnetic mechanism pulls the main contacts closed.
3. Three-phase power is supplied to the motor or load.
4. When the coil is released, contacts open and disconnect power.

Typical controlled equipment:

• Motors
• Pumps
• Fans
• Compressors
• Heating equipment
• Industrial machinery

Key Features

• High current switching capability (85A)
• Compact IEC design
• 3-phase motor control capability
• Front and side accessory compatibility
• Auxiliary contact for feedback or control circuits
• Suitable for industrial motor starter applications
• Designed for reliable frequent switching operation

Advantages

• Reliable motor control: suitable for industrial continuous-duty applications.
• Space-saving design: compact compared with traditional NEMA contactors.
• Easy maintenance: modular accessories simplify replacement and expansion.
• PLC-friendly: commonly integrated into automated control systems.
• Industrial durability: designed for factory environments.

Applications

• Industrial motor starters
• Conveyor systems
• HVAC equipment
• Pumps and compressors
• Packaging machinery
• Production line equipment
• Factory automation control panels
