ABB YXT 116 expansion board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Product Description

The ABB YXT116 Expansion Board is designed to extend the I/O capacity, communication interfaces, or signal processing capabilities of ABB industrial control systems.
It works together with ABB main control boards such as the YXR, YXP, and YXM series, providing additional digital/analog channels or communication ports for complex automation applications.

The YXT116 features an industrial-grade design, high noise immunity, and excellent compatibility, ensuring reliable operation in demanding industrial environments.

Technical Specifications

• Model: YXT116

• Manufacturer: ABB

• Type: Expansion Board

• Power Supply: 24 V DC (±10%)

• Power Consumption: Approx. 6 W

• Expansion Interface Type:

  • System Bus Connector

  • I/O Extension Port

  • Optional Communication Slot

• Supported Signals: Digital / Analog

• Channel Capacity: 8–32 channels (configurable)

• Communication Interfaces:

  • RS-232 / RS-485 Serial Ports

  • CAN Bus / Profibus (optional)

  • System Backplane Bus

• Signal Isolation: ≥ 1500 V RMS (optically isolated)

• Operating Temperature: 0°C to +55°C

• Storage Temperature: -25°C to +70°C

• Relative Humidity: ≤ 90% (non-condensing)

• Protection Class: IP20

• Dimensions: Approx. 160 × 100 mm

• Weight: Approx. 0.3 kg

• Mounting Type: Slot / Modular Rack Mount

Features & Advantages

1. Powerful Expansion Capability: Extends system I/O and communication resources.

2. Modular and Flexible: Easy installation and maintenance.

3. High Compatibility: Fully compatible with ABB YXR, YXP, and YXM control systems.

4. Industrial Reliability: Designed for harsh environments with strong EMI protection.

5. Versatile Signal Support: Handles both digital and analog signals.

6. Fast Communication: Supports high-speed system bus connections.

7. Built-in Diagnostics: LED indicators and self-check functions.

8. Customizable Configuration: Optional interfaces for specific applications.

Application Fields

• Industrial automation and process control systems

• Power generation and substation automation

• Robotics and motion control systems

• Drive and servo control expansion

• Chemical, metallurgical, and paper production lines

• DCS and PLC system extension

• Signal processing and data acquisition systems

Precautions

1. Disconnect power before installation or maintenance.

2. Use anti-static wrist straps and proper grounding during handling.

3. Ensure compatibility between the expansion board and main CPU board.

4. Use shielded and grounded cables to prevent interference.

5. Avoid exposure to high temperature, humidity, or corrosive gases.

6. Regularly inspect connector contacts and keep them clean.

7. Perform firmware updates only with ABB-certified tools.

8. Maintain adequate ventilation to prevent overheating.
